Warnings, Cautions and Others
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the
plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point,
then obtain an appropriate safety approved extension
lead or consult your dealer.
BE SURE to replace the fuse only with an identical
approved type, as originally fitted.
If nontheless the mains plug is cut off ensure to remove
the fuse and dispose of the plug immediately, to avoid a
possible shock hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is
marked with the letter E or by the safety earth symbol or
coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured
in accordance with the following code:
Blue : Neutral
Brown : Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured
black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture. Caution ÐÐ
switch!
Disconnect the mains plug to shut the power off completely
(the STANDBY/ON lamp goes off).
The
switch in any position does not disconnect the
mains line.
¥ When the unit is on standby, the STANDBY/ON lamp
lights red.
¥ When the unit is turned on, the STANDBY/ON lamp lights
green.
The power can be remote controlled.
Ð G-1 Ð
CA-MXS6MDR[B].Safety00.8.2, 10:43 AM 2
Page 2
Front view Side view
Caution: Proper VentilationTo avoid risk of electric shock and fire, and to prevent damage,
locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by
the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path
for ventilation by placing on a stand with a height of 10 cm
or more.
Ð G-2 Ð
IMPORTANT FOR LASER PRODUCTS
REPRODUCTION OF LABELS
CLASS 1
LASER PRODUCT
1. CLASS 1 LASER PRODUCT
2.DANGER: Invisible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3.CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to
qualified service personnel.
1CLASSIFICATION LABEL, PLACED ON REAR
ENCLOSURE2WARNING LABEL, PLACED INSIDE THE UNIT
DANGER: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgå udsæt-
telse for stråling (d)
VARNING: Osynlig laser-
strålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja suo-
jalukitus ohitettaessa olet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)
CA-MXS6MDR CA-MXS6MDR
1 cm 1 cm 15 cm
15 cm 27 cm
27 cm
16.5 cm
15 cm
10 cm
