Page 1
Caution Ñ STANDBY/ON button!
Disconnect the mains plug to shut the power off
completely. The STANDBY/ON
button in any
position does not disconnect the mains line. The
power can be remote controlled.
Precauci-n ÐÐ Interruptor STANDBY/ON
!
Desconectar el cable de alimentaci-n para
desactivar la alimentaci-n totalmente. Cualquier
que sea la posici-n de ajuste del interruptor
STANDBY/ON
, la alimentaci-n no es cortada
completamente. La alimentaci-n puede ser
controlada remotamente.
Precau-o ÐÐ Interruptor STANDBY/ON
!
Desconectar o cabo de alimenta-o para desligar
a alimenta-o por completo. Qualquer que seja a
posi-o de ajuste do interruptor
STANDBY/ON
, a alimenta-o n-o Ž
completamente cortada. A alimenta-o pode ser
controlada remotamente.
Ð G-1 Ð Warnings, Cautions and Others
Avisos, precauciones y otras notas
Advertncias, precau-es e outras notas
CA-MXGT90&80&70[UJ,UW]Safetyf3/21/01, 6:24 PM 1
Page 2
English
Portugus Espa-ol
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or
moisture. CAUTION
¥ Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get out.)
¥ Do not place any naked flame sources, such as lighted
candles, on the apparatus.
¥ When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
¥ Do not use this apparatus in a bathroom or places with water.
Also do not place any containers filled with water or liquids
(such as cosmetics or medicines, flower vases, potted plants,
cups, etc.) on top of this apparatus.
PRECAUCIîN
¥ No obstruya las rendijas o los orificios de ventilaci-n.
(Si las rendijas o los orificios de ventilaci-n quedan tapados
con un peri-dico, un trozo de tela, etc., no se podr- disipar el
calor).
¥ No ponga sobre el aparato ninguna llama al descubierto,
como velas encendidas.
¥ Cuando tenga que descartar las pilas, tenga en cuenta los
problemas ambientales y observe estrictamente los
reglamentos o las leyes locales sobre disposici-n de las
pilas.
¥ No utilice este aparato en el cuarto de ba-o o en lugares
donde hay agua. Tampoco coloque ningœn recipiente que
contenga agua u otros lquidos (frascos de cosmŽticos o
medicinas, floreros, macetas, vasos, etc.) encima de este
aparato.
AVISO
¥ N-o obstrua as aberturas e orifcios de ventila-o. (Se os
orifcios ou aberturas de ventila-o estiverem obstrudos por
qualquer papel ou tecido, n-o haver- circula-o do ar
quente.)
¥ N-o coloque nenhum objeto com chamas, como velas
acesas, sobre o aparelho.
¥ Ao descartar as baterias, leve em considera-o os proble-
mas que possam ser causados ao meio ambiente e os
regulamentos e leis locais e governamentais sobre recolhi-
mento dessas baterias devem ser rigorosamente seguidos.
¥ N-o utilize este aparelho em banheiros ou em locais com
-gua. AlŽm disso, n-o coloque nenhum recipiente com -gua
ou qualquer tipo de lquido (como cosmŽticos ou remŽdios,
vasos com flores, plantas, xcaras, etc.) sobre o aparelho. PRECAUCIîN
Para reducir riesgos de choques elŽctricos,
incendio, etc.:
1. No extraiga los tornillos, los cubiertas ni la
caja.
2. No exponga este aparato a la lluvia o a la
humedad.
PRECAU-ÌO
Para reduzir riscos de choques elŽtricos,
incndio, etc.:
1. N-o remova parafusos e tampas ou
desmonte a caixa.
2. N-o exponha este aparelho ˆ chuva nem
ˆ umidade.
Ð G-2 Ð
CA-MXGT90&80&70[UJ,UW]Safetyf3/21/01, 6:24 PM 2
Page 25
Ð 21 Ð
English
Using the Microphones
You can enjoy singing along (Karaoke) and microphone
mixing by using two microphones.
¥ MIC LEVEL adjustment is valid for both microphones
connected MIC 1 and MIC 2 jacks.
IMPORTANT:
¥Always set MIC LEVEL to MIN when connecting or
disconnecting the microphone.
¥ When you do not use the microphone, keep the
microphones unconnected.
Sining along Ñ Karaoke
Vocal Masking
Vocal Masking reduces the lead vocal of the playing source,
and allows you to replace it by singing into the microphones
as the music plays.
1 Turn MIC LEVEL to MIN.
2 Connect the microphone(s) (not
supplied) by plugging it into
MIC 1 and/or MIC 2 jack.
3 Press KARAOKE on the remote
control.
The karaoke ( ) indicator lights up on the
display.
4 Start playing the source Ñ CD, tape, or other
connected component.
5 Turn MIC LEVEL and
VOLUME as you sing into the
microphone(s).
¥ By pressing REC START/STOP, you
can record your singing along if you
want. (For more details, see page 18.)
To apply an echo to your voice
Press ECHO on the remote control so that the
echo (
) indicator lights up on the display.
Each time you press the button, the echo level changes as
follows:
¥ As the number increases, a stronger echo effect applies to
your voice.
If howling or squealing (feedback) occurs while using
the microphone(s)
Take the following actions to prevent these noises.
¥ Adjust MIC LEVEL and VOLUME.
¥ Avoid pointing the microphone(s) towards the speakers.
¥ When two microphones are connected, turn off the ON/OFF
switch on the unused microphone.
If you use the following sources as the playing source
for Karaoke (Vocal Masking), you cannot get the
satisfactory results
¥ Radio programs Ñ a radio signal is not as reliable as the signals
coming from a tape or CD.
¥ Monaural sources.
¥ Poorly dubbed tapes.
¥ Sources recorded with duets, strong echo, a chorus, or only a few
instruments.
Microphone mixing
When you sing along with multiplex tapes or CDs, follow the
procedure below:
1 Connect the microphone(s).
2 Start playing the source Ñ CD, tape, or other
connected component.
3 Turn MIC LEVEL and
VOLUME as you sing into the
microphone(s).
¥ By pressing REC START/STOP, you
can record your singing along if you
want. (For more details, see page 18.)
To use microphone only
Without any background sound, you can use your
microphone(s), and record it if you want.
1 Connect the microphone(s).
2 Press CD 3/8, then 7.
No background sound will be heard.
3 Turn MIC LEVEL and
VOLUME as you sing into the
microphone(s).
¥ By pressing REC START/STOP, you
can record your singing along if you
want. (For more details, see page 18.)
ECHO 1ECHO 2
ECHO OFF
(Canceled)ECHO 3
EN18-30.CA-MXGT90&80&70[UJ,UW]f3/22/01, 10:09 AM 21
