Jvc CAC 330 Service Manual

Page 1

CA-C33O

, .JVIZ.I
SERVICE MANUAL

CA-C330

Pick up OPTIMA-6
CD SIGNAtL PRQCESSEROR TC9284AF
wrth In 1 blt DAC
CD SERVO TA8191F
Area Suffix
A ..... Austraria
BS .. . V the UK.
C ..... Canada
.._-A -=--__ -~ EF H .s Continental Europe
11' 17° EN Scandinavia
I m@m{ G ..... Germany
m GI Italy
J ...... U.S.A
UT Taiwan
COMPACT US . . . . Singapore
Egg VX Eastern Europe
U ..... Other Countries
DIGITALAUDIO
Contents
Safety Precautions ........................ 1-2 Adjustment Procedures ................... 1-38
Inportant for Laser Products .............. 1-3 Block Diagrams ......................... 1-43
Instruction Book .......................... 1-4 Connection Diagram ..................... 1-44
Description of ICs ....................... 1-17 Printed Circuit Boards ................... 145
Internal Connection for the FL ........... 1.28 Schematic Diagrams 1-51
Disassembly Procedures .................. 1-31 Parts List ................................ 2-1
N0. 20509U

Apr. 1995

Page 2

CA-C33O

- Safety Precautions

1.The design of this product contains special hardware and many circuits and components
specially for safety purposes. For continued protection, no changes should be made to the
original design unless authorised in writing by the manufacturer. Replacement parts must
be identical to those used in the original circuits.

2. Any unauthorised design alterations or additions will void the manufacturer's guarantee ;
furthermore the manufacturer cannot accept responsibility for personal injury or property
damage resulting therefrom.

3. Essential safety critical components are identified by (A) on the Parts List and by shading
on the schematics ,and must never be replaced by parts other than those listed in the
manual. Please note however that many electrical and mechanical parts in the product have
special safety related characteristics. These characteristics are often not evident from visual
inspection. Parts other than specified by the manufacturer may not have the same safety
characteristics as the recommended replacement parts shown in the Parts List of the service
manual and may create shock,fire ,or other hazards.

4. The leads in the products are routed and dressed with ties, clamps. tubings, barriers and
the like to be separated from live parts, high temperature parts. moving parts and/or sharp
edges for the prevention of electric shock and fire hazard. When service is required, the
original lead routing and dress should be observed, and it should be confirmed that they
have been returned to normal, after re-assembling.

Warning

1. Service should be performed by qualified personnel only.
2. This equipment has been designed and manufactured to meet international safety standards.

3. It is the legal responsibility of the repairer to ensure that these safety standards are
maintained.

4. Repairs must be made in accordance with the relevant safety standards.
5. It is essential that safety critical components are replaced by approved parts.
6. If mains voltage selector is provided, check setting for local voltage.

1-2

Page 35

CA-C330

(11) Damper removal

1. Remove the cassette mechanism

2. Remove the spring holding the cassette holder.

3. Press the tab which secures the damper to
remove the damper.(See the arrow shown in the
figure below)

(12) Cassette holder removal

L Remove the Cassette mechanism assembly.

2. Remove the spring holding the cassette holder.
3. Remove Cassette holder .

A

:1
gm, 0 Q
g] Damper

Fig 17 Door damper view

Front panel Assy

Cassette holder

Spring

Fig 18 Side view

(13) Capstan motor removal.
1. Remove the cassette mechanism.

Remove the cassette deck control PCB.
Remove the Sscrews holding the bracket.
Remove the capstan motor with the bracket.

9"???"

Remove the 2screws fixing the motor and the braket.

Reel ,cam motor PCB

Cam swich PCB\

0

.~
H;

W

Capstan motor

Fig 19 Cassette mechanism bottom view

© .. SDSFZGOSZ

1-35
