Extracted text from Jvc 4VR 5426 X Owners Manual (Ocr-read)


Page 2

PRECAUTIONS

' Leave space around the receiver for ventilation.

' Do not connect equipment requiring more than the rated power to the AC
sockets on the rear panel.

- Turn off the power before connecting any components to avoid damage to
speakers.

' Connect the speaker and input terminals correctly as wrong polarity or shorting
will result in unstable sound or the blowing of a fuse. A poor ground contact
may result in hum which may damage the speakers.

' Use speakers with the correct impedance. (See below)

* Do not remove the cabinet screws or disassemble the cabinet. There are no user
serviceable parts inside.

Take care with the AC plug. 00 not bend the cord perpendicularly to the plug:
grasp the plug when pulling it from the AC outlet and dont apply any force to
the cord.

0 CD4 adjustment is to match the cartridge and stylus with the demodulator. If
this is not done CD-4 sound may deteriorate. (See page 8.)

0 If your receiver is too close to a TV receiver yoq may have interference problems
when playing 004 records. Move the receiver 3 to 4 ft from the TV.

SPEAKERS

When you are playing 4-channel sound the speakers can be between 40 and 160.
When you are playing BTL double power 2~channel sound the speakers should not
be less than 80.

With JVC's 4VR-5426X 4-channel and double power BTL operations can be selected
by the Speaker switch. When speakers are connected with a common negative
wound, with the Speaker switch in its OFF position sound may be heard and when
it is in its BTL position abnormal effects may be heard.

The speaker switching boxes most commonly used use a common negative ground
and so if you are using a switching box only the 4- CH position should be used.

CONTENTS

PRECAUTIONS .................................................. 1
WARNING ...................................................... 1
CONNECTION DIAGRAM ......................................... 2
REAR PANEL ................................................... 3
CONNECTING SPEAKERS ......................................... 4
FRONT PANEL .................................................. 5
ANTENNA CONNECTION AND PROTECTION FUSES .................. 7
PLAYING CD4 4'CHANNEL RECORDS .............................. 7
PLAYING 4-CHANNEL MATRIX 0R 2-CHANNEL RECORDS ............. 7
CD4 ADJUSTMENT .............................................. 8
FM 4-CHANNEL ................................................. 9
RECEIVING BROADCASTS ........................................ 9
PLAYING TAPES ................................................ 10
RECORDING AND MONITORING ................................... 10
BALANCING SPEAKERS .......................................... 11
BTL DOUBLE POWER 2-CHANNEL SOUND ........................... 11
CONNECTION OF NOISE REDUCTION UNIT ......................... 11
PERFORMANCE GRAPHS ......................................... 12
SPECIFICATIONS ................................................ 13

WARNINGTO PREVENT FIRE 0R SHOCK HAZARD, DO NOT Ex-
POSE THIS APPLIANCE T0 RAIN OR MOISTURE. (UL APPROVED.)
