Page 1
Introduction
W
elcome to the Jeff Rowland Design Group family and congratulations on your purchase of the Model 6 Amplifiers.
þ
These mono Amplifiers are unquestionably considered to be one of the finest in their class.
þ
With the combination of
industrial-grade active and passive devices, precision electronic circuitry and accurately machined chassis components
throughout, your Model 6 Mono Amplifiers will offer you many years of musically satisfying enjoyment.
þ
Please take a
few moments to read the remainder of this Owners Manual.
þ
A thorough understanding of the operational features
will allow you to gain the maximum performance and ease of use for which these Amplifiers were designed.
þ
Please
note that your Model 6 Mono Amplifiers are marked with serial numbers beginning with the letter A.
þ
These numbers
are recorded below and are also located on the rear panel of each chassis.
þ
Please include these numbers with any
correspondence regarding your Model 6 Amplifiers.
þ
It has been my joy to create audio components of enduring
value which will reflect a higher ideal of musical and artistic expression.
þ
It is my hope that these qualities will enrich
your experience of ownership.
Enjoy the music!
Jeff Rowland
President
þJeff Rowland Design Group, Inc.
2911 North Prospect Street
Colorado Springs, CO 80907
Phone: 719/473-1181
Fax: 719/633-4158
Page 2
Product Features þ
XLR Balanced Input jacks for balanced (Differential Mode-„¢) system
configurations
þ
XLR to RCA Input adapters included
þ
User-selectable overall gain of 26 or 32 dB
þ
User-selectable input impedance of 18k½(HI) or 600½(LO)
þ
All internal signal circuitry is totally isolated from chassis and system
ground potentials to eliminate noisy ground loops and to provide
extreme immunity from RF interference
þ
Optional remote (wired or wireless power ON/OFF switching)
þ
Automatic temperature stabilizing circuitry maintains constant
operating temperature
þ
Standby power condition reduces warm-up time
þ
Fail-safe operation provided by user-resetable AC circuit breaker
located on rear panel
þ
Quiet, transient-free operation during power and function mode
switching
þ
Automatic input muting under anomalous input or output operating
conditions
þ
Balanced Differential Mode-„¢ circuit topology implemented from input
to output
þ
Plug-in modules, containing critical electronic circuitry, enhance
thermal stability, mechanical integrity and serviceability
þ
Low-resonance, structurally integrated chassis of precision machined
aluminum alloy components.
Introduction / Product Features
