Table of Contents
Section 1: Important Safety Instructions ..................3
Section 2: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Section 3: Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Section 4: Setting Up Your MSC1 . . . . . . . . . . . . . . . . . . . . . . . 7
Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audio Connections . . . . . . . . . . . . . . . . . . . . . . . . . 7
Getting Sound ............................. 8
MSC1 System Example . . . . . . . . . . . . . . . . . . . . . 9
Section 5: Features and Operation . . . . . . . . . . . . . . . . . . . . . 10
MSC1 front panel controls ...................10
MSC1 rear panel connectors . . . . . . . . . . . . . . . . . 14
Section 6: Installing MSC1 Control Center Software
- Windows Operating System . . . . . . . . . . . . . . . .16
To Uninstall the MSC1 Control Center Software .18
Launching the MSC1 Control Center Software
- Windows Operating System ................ 19
Section 7: Installing MSC1 Control Center Software
- Macintosh Operating System ................20
To Uninstall the MSC1 Control Center Software . .22
Launching the MSC1 Control Center Software
- Macintosh Operating System ................23
Section 8: Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Section 9: Troubleshooting ........................... 26
Section 10: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Section 11: JBL Service Contact Information ............. 32
Section 12: Product Warranty Information . . . . . . . . . . . . . . .33
Page 2
3
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
manufacturers instructions.
8. Do not install near any heat sources such as radiators, heat registers, \
stoves
or other apparatus that produce heat.
9. Protect the power cord from being walked on or pinched particularly at p\
lugs,
convenience receptacle and the point where the power cord connects
to the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Unplug this apparatus during lightning storms or when unused for long
periods of time.
12. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, including: power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into \
the
apparatus, the apparatus has been exposed to rain or moisture, does not \
operate normally, or has been dropped.
13. The appliance coupler of the power supply cord is used as the ultimate
disconnect device from the mains. The appliance coupler shall remain readily
operable.
14. The apparatus shall be connected to mains socket outlet with a protectiv\
e
earthing connection.
15. POWER ON/OFF SWITCH: The power switch DOES NOT interrupt connection
to the mains. To disconnect the product from the mains, remove the power
cord connector from the power input on the rear panel of the product.
16. Caution: This product is used to control loudspeaker volume. Very loud
playback volume can damage hearing. Never adjust speaker volume to
produce an output level that is audibly painful.
WARNING: To reduce the risk of fire or electrical shock, do not expose the apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus. As with any electronic product, use care
not to spill liquids into any part of the system. Liquids can cause a failure and/or a fire hazard.
CAUTION! TO REDUCE THE RISK OF ELECTRONIC SHOCK - DO NOT REMOVE
COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
PERSONNEL. DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
Section 1: Important Safety Instructions
