jbl d 38 service manual

Extracted text from jbl d 38 service manual (Ocr-read)

Page 1

Grille Retainer (4) 62130 Tweeter 334659-001 Mid Range 334657-001 Screw (4) #6 x C\v PPH 63563Screw (4) #6 x C\v PPH 63563 Grille 334793-001 Logo Plate 334884-001 Screw (4) #6 x C\v PPH 63563 Woofer 334624-001 Crossover Network 334787-001 Enclosure D38(Not for sale) D38 Decade Series D38 - Decade Series 9-99 JBL Consumer Products, Inc. 250 Crossways Park Dr., Woodbury, New York 11797 EXPLODED VIEW
