WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
dangerous voltage within the products enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNINGRISK OF ELECTRIC SHOCK
DO NOT OPEN RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS
Important Safeguards
PORTABLE CART WARNING
S3125A
1.Read Instructions -“ All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions -“ The safety and operating instructions
should be retained for future reference.
3.Heed Warnings -“ All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions -“ All operating and use instructions should
be followed.
5.Cleaning -“ Unplug the appliance from the wall outlet before
cleaning. The appliance should be cleaned only as recom-
mended by the manufacturer.
6.Attachments -“ Do not use attachments not recommended
by the appliance manufacturer as they may cause hazards.
7.Water and Moisture -“ Do not use the appliance near water -“
for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool;
and the like.
8.Accessories -“ Do not place the appliance on an unstable
cart, stand, tripod, bracket, or table. The appliance may fall,
causing serious injury to a child or adult, and serious damage
to the appliance. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with the
appliance. Any mounting of the appliance should follow the
manufacturers instructions, and should use a mounting ac-
cessory recommended by the manufacturer.
9. An appliance and cart combi-
nation should be moved with
care. Quick stops, excessive
force, and uneven surfaces
may cause the appliance and
cart combination to overturn.
10.Ventilation -“ Slots and openings
in the cabinet are provided for
ventilation and to ensure reli-
able operation of the appli-
ance and to protect it from overheating, and these open-
ings must not be blocked or covered. The openings should
never be blocked by placing the appliance on a bed, sofa,
rug, or other similar surface. The appliance should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided. There should be free
space of at least 20 cm (8 in.) and an opening behind the
appliance.
11.Power Sources -“ The appliance should be operated only
from the type of power source indicated on the marking la-
bel. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power com-
pany.
12.Grounding or Polarization -“ The appliance may be equipped
with a polarized alternating current line plug (a plug having
one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.13. Power-Cord Protection -“ Power-supply cords should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular at-
tention to cords at plugs, convenience receptacles, and the
point where they exit from the appliance.
14.Outdoor Antenna Grounding -“ If an outside antenna or
cable system is connected to the appliance, be sure the
antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANSI/
NFPA 70, provides information with regard to proper ground-
ing of the mast and supporting structure, grounding of the
lead-in wire to an antenna-discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection
to grounding electrodes, and requirements for the ground-
ing electrode. See Figure 1.
15.Lightning -“ For added protection for the appliance during a
lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and dis-
connect the antenna or cable system. This will prevent dam-
age to the appliance due to lightning and power-line surges.
16.Power Lines -“ An outside antenna system should not be lo-
cated in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
17.Overloading -“ Do not overload wall outlets, extension cords,
or integral convenience receptacles as this can result in a risk
of fire or electric shock.
18.Object and Liquid Entry -“ Never push objects of any kind into
the appliance through openings as they may touch danger-
ous voltage points or short-out parts that could result in a fire
or electric shock. Never spill liquid of any kind on the appli-
ance.
19.Servicing -“ Do not attempt to service the appliance yourself
as opening or removing covers may expose you to danger-
ous voltage or other hazards. Refer all servicing to qualified
service personnel.
20.Damage Requiring Service -“ Unplug the appliance form the
wall outlet and refer servicing to qualified service personnel
under the following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen into the
appliance,
C. If the appliance has been exposed to rain or water,
D. If the appliance does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and
will often require extensive work by a qualified techni-
cian to restore the appliance to its normal operation,
E. If the appliance has been dropped or damaged in any
way, and
F. When the appliance exhibits a distinct change in perfor-
mance -“ this indicates a need for service.
Page 2
3
Precautions
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H) NEC -“ NATIONAL ELECTRICAL CODEELECTRIC
SERVICE
EQUIPMENTGROUND
CLAMPANTENNA
LEAD IN
WIRE
S2898A
21.Replacement Parts -“ When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same character-
istics as the original part. Unauthorized substitutions may re-
sult in fire, electric shock, or other hazards.
22.Safety Check -“ Upon completion of any service or repairs to
the appliance, ask the service technician to perform safety
checks to determine that the appliance is in proper opera-
tion condition.
23.Wall or Ceiling Mounting -“ The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
24.Heat -“ The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other ap-
pliances (including amplifiers) that produce heat.
TapedFIGURE 1:
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL
ELECTRICAL CODE, ANSI/NFPA 70
1. Warranty Claim
You can find the serial number on the rear panel of this unit.
In case of warranty claim, please report this number.
2. Recording Copyright
Recording of copyrighted material for other than personal
use is illegal without permission of the copyright holder.
3. AC Fuse
The fuse is located inside the chassis and is not user-service-
able. If power does not come on, contact your Onkyo autho-
rized service station.
4. Care
From time to time you should wipe the front and rear panels
and the cabinet with a soft cloth. For heavier dirt, dampen
a soft cloth in a weak solution of mild detergent and water,
wring it out dry, and wipe off the dirt. Following this, dry
immediately with a clean cloth. Do not use rough material,
thinners, alcohol or other chemical solvents or cloths since
these could damage the finish or remove the panel letter-
ing.
5. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE
FOLLOWING SECTION CAREFULLY.
The voltage of the available power supply differs according
to country or region. Be sure that the power supply voltage
of the area where this unit will be used meets the required
voltage (e.g., AC 120 V, 60 Hz) written on the rear panel. For U.S. model
Note to CATV system installer:
This reminder is provided to call the CATV system installers
attention to Article 820-40 of the NEC, ANSI/NFPA 70, which
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
FCC Information for User
CAUTION:
The user changes or modifications not expressly approved
by the party responsible for compliance could void the
users authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and re-
ceiver.
-Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician
for help.
For Canadian model
CAUTION: THIS DIGITAL APPARATUS DOES NOT EXCEED
THE CLASS B LIMITS FOR RADIO NOISE EMISSION FROM
DIGITAL APPARATUS SET OUT IN THE RADIO INTERFERENCE
REGULATIONS OF THE CANADIAN DEPARTMENT OF COMMU-
NICATIONS.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Modele pour les Canadien
ATTENTION: L'INTERFÉRENCE RADIO ÉLECTRIQUE GÉNÉRÉE
PAR CET APPAREIL NUMÉRIQUE DE TYPE B NE DÉPASSE PAS
LES LIMITES ÉNONCÉES DANS LE RÈGLEMENT SUR LES PERTUR-
BATIONS RADIO ÉLECTRIQUES, SECTION APPAREIL
NUMÉRIQUE, DU MINISTÈRE DES COMMUNICATIONS.
Sur les modèles dont la fiche est polarisée:
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU
FOND.
Precautions during unpacking
- The unit is extremely heavy, so be careful when lifting it
so as not to cause an injury. Do not lift or move the unit
by holding it at the door on the front panel. Doing so
may damage the front door.
- When packaged, the door on the front panel is taped
to the unit. Before use, be sure to remove this tape.
OffOn
Standby/On Standby
Master Volume
Power
Display DVD
Video 1Video 2Video 3Video 4Video 5 Tape 1Tape 2AM
FM
Phono
C DOpen/Close Zone 2()
GRN
Rec()
RED
DTR-9.1
