INTRODUCTION
The Infinity CC-2 is a low-profile 2-way speaker system designed
specifically for center-channel use. It features extended high-frequency
response and a fine-adjustment voice-matching control, all designed to
help seamlessly integrate the sound of the CC-2 with other speakers in
your home theater system.
This efficient, magnetically-shielded speaker requires only minimal
power to produce sound levels greater than those heard in a movie
theater. The accompanying speaker stand allows a vertical tilt range of
25 degrees for ideal sound coverage whether placed on top of or below
the television.
Please read the remaining pages before connecting and operating the
CC-2 speaker. Maximum performance is dependent on following these
instructions, as well as those listed in the ownerÕs manuals of associated
components in your home theater system. Save these instructions for
future reference. These speakers are covered by a limited five-year
warranty, so save the bill of sale to protect your purchase and aid in any
service-related questions.
U NPACKING T HE S PEAKER
Finish unpacking the speaker and check the contents. If you suspect
damage from transit, report it immediately to your dealer and/or
delivery service. Keep the shipping carton and packing materials for
future use.
Please verify that the package contains the following items:
u (1) CC-2 Center-Channel Speaker
u (1) Speaker Stand
u (1) OwnerÕs Manual
u (1) Warranty Card
You may also need the following tools and supplies:
u High-quality speaker wire
u Wire strippers
u Banana plugs or spade terminals (if desired)
CC2 Ins 9/11/98 3:50 PM Page 1
Page 2
2uInfinity CC-2 Center-Channel Speaker OwnerÕs Manual
Figure 1. The CC-2 center-channel
speaker can be placed on top of a
television or on shelf directly
above or below the set.
P LANNING Y OUR S YSTEM
To help plan your home theater system, study the layout in Figure 1,
which represents a typical living room where the home theater system
is the main focus.
For best results, the CC-2 center-channel speaker should be placed
horizontally in its stand on top of the television or on a shelf directly
above the set (see Placement on the next page). Or, if space is at a
premium, an alternate location is below the television on a shelf. Make
sure the CC-2 faces the viewing audience.
Optional
Subwoofer
(on floor)
Listening Area Front Left
(on shelf) Front Right(on shelf)
CC-2 for Center(on top or below TV)
Rear Right
Surround
(on stand)
Rear Left
Surround
(on stand)
