Page 1
THIS INFINITY PRODUCT IS DESIGNED FOR 120-VOLT USE ONLY! FOR DETAILED SAFETY PRECAUTIONS,
PLEASE SEE FOLLOWING PAGE IN THIS OWNER'S MANUAL FOR ÒIMPORTANT SAFETY INSTRUCTIONS.Ó
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of uninsulated
Òdangerous voltageÓ within the
productÕs enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
product.
LÕ Žclair avec le symbole de la flche, placŽ dans les limites dun triangel ŽquilatŽral est
prŽvu pour avertir lÕutilisateur de la prŽsence de Òtension dangereuseÓ non isolŽe dans
lÕenceinte du produit qui pourrait tre dÕune importance suffisante pour prŽsenter un
resque dÕŽlectrocution aux personnes.
Le point dÕexclamation dans un triangel Žquilateral est prŽvu pour avertir lÕutilisateur
de la prŽsence dÕinstructions importantes pour les opŽrations et lÕentretien (service)
dans les manuels fournis avec lÕappareli.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND.
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD Ð DO NOT OPEN.
AVIS: RISQUE DE CHOC ELECTRIQUE Ð NE PAS OUVRIR.
CUIDADO: PELIGRO DE CHOQUE ELECTRICO Ð NO ABRIR.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (0R BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL
Este destello luminoso con un smbolo de punta de flecha dentro de un tri-ngulo
equil-tero tiene el objectivo de alertar al usuario sobre la presencia de Òvoltaje
peligrosoÓ no aislado dentro de la caja del producto que puede ser de magnitud lo
suficientemente grande para constituir un riesgo de choque elŽctrico para las personas.
Este punto de exclamaci-n dentro de un tri-ngulo equil-tero tiene el objectivo de
alertar al usuario sobre la existencia de instrucciones operativas y de mantenimiento
(servicio) importantes en la literatura que acoma-a el aparato.
CUIDADO: PARA REDUCIR EL RIESGO DE CHOQUE ELƒCTRICO, NO
RETIRE LA CUBIERTA (O RESPALDO). DENTRO NO HAY PIEZAS A
LAS QUE EL USUARIO PUEDA DAR SERVICIO. REMITA EL SERVICIO
AL PERSONAL DE SERVICIO CALIFICADO.
!
Page 2
IMPORTANT SAFETY INSTRUCTIONS
1)Read Instructions ÐAll the safety and operating instructions should be
read before the product is operated.
2)Retain Instructions ÐThe safety and operating instructions should be
retained for future reference.
3)Heed Warnings ÐAll warnings on the product and in the operating
instructions should be adhered to.
4)Follow Instructions ÐAll operating and use instructions should be
followed.
5)Cleaning ÐUnplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Exception: A product that is meant for uninterrupted service and that for
some specific reason, such as the possibility of the loss of an authorization
code for a CATV Converter, is not intended to be unplugged by the user for
cleaning or any other purpose, may exclude the reference to unplugging the
product in the cleaning description otherwise required in number 5.
6)Attachments ÐDo not use attachments not recommended by the product
manufacturer as they may cause hazards.
7)Water and Moisture ÐDo not use this product near water Ð for example,
near a bathtub, washbowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.
8)Accessories ÐDo not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturerÕs instructions, and should use a
mounting accessory recommended by the
manufacturer.
9)A product and cart combination should be
moved with care.Quick stop, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
10)Ventilation ÐSlots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to protect it
from overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or
the manufacturerÕs instructions have been adhered to.
11)Power Sources ÐThis product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.
12)Grounding or Polarization ÐThis product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized
plug.
13)Power-Cord Protection ÐPower-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
14)Outdoor Antenna Grounding Ð If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size for grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding
electrode. See Figure A.15)Lightning ÐFor added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the product due to lightning and power-line
surges.
16)Power Lines Ð An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
17)Overloading ÐDo not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
18) Object and Liquid Entry ÐNever push objects of any kind into this
product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill liquid
of any kind on the product.
19)Servicing ÐDo not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
20) Damage Requiring Service ÐUnplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
a)When the power-supply cord or plug is damaged.
b)If liquid has been spilled, or objects have fallen into the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation.
e)If the product has been dropped or damaged in any way.
f)When the product exhibits a distinct change in performance Ð this
indicates a need for service.
21)Replacement Parts ÐWhen replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer or
that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
22)Safety Check ÐUpon completion of any service or repairs to this
product, ask the service technician to perform safety checks to determine that
the product is in proper operating condition.
23) Wall or Ceiling Mounting ÐThe product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
24)Heat ÐThe product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers) that
produce heat.
ANTENNA
LEAD-IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENTANTENNA
DISCHARGE UNIT
(NEC SECTION 810-21)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC SECTION 810-21) Figure A
