MODEL KS-3200H SERVICE MANUAL

DISASSEMBLY

PANEL HOLDING SCREWS
BACK COVER FRONT
HOLDING SCREWS

4. Removal of dial lamp cover.
Remove two screws holding dlial lamp cover shown in

Fig. 7.

1. Removal of back cover
Remove three screws holding back cover shown in Fig. 3_

Fig. 3
CHASSIS HOLDING SCREWS

2. Removal of chassis.
Fig. 6
DIAL LAMP COVER INDICATOR
L LAMP COVER
HOLDING SCREWS(2) HOLDING D'A
SCREws HOLDING SCREWSU)

After pulling out the six knobs and apower switch knob,
remove four screws holding chassis and take out the
chassis shown in Fig. 4.

5. Removal of indicator.
Remove two screws holding indicator shown in Fig. 7.

Fig. 4 ROTARY SWITCH
FRONT PANEL HOLDING SCREWS HOLDING NUTS

3. Removal of front panel.
Remove five screws holding front panel shown in Figs.
5 1 °~ RFAIF BLOCK

HOLDING
SCREWS

6. Removal of circuit board.
Remove five screws holding RF-IF block, six screws
holding AF block, two screws holding power block and two
screws holding equalizer block shown in Fig 5.
Remove four nuts holding rotary switches shown in Fig. 3.

POWER BLOCK
HOLDING SCREWS ,
