@HITACHI
smwc: MANUAL mm
SPECIFICATIONS
Design and specifications subject to change without notice for further
improvement.
Type erpeed belt drive system Frequency response IO - 25,000 Hz
Platter Aluminum alloy diercast, 310 mm outer Output voltage 3 mV at 1 kHz 50 mm/sec.
diameter Channel difference 1 dB at 1 kHz
Motor 4-pole synchronous motor Channel separation 20 dB at 1 kHz
Speed 2 speeds, 33-1/3 and 45 rpm Tracking force 1.5 e 2.5 9 (recommended 2 9)
SIM 65 dB lDINrB) Stylus tip Diamond stylus [DS-STSOI
Wow 8 Flutter 0.06% WRMS Power source 120 V 60 Hz for U.S.A. 8t Canada standard
Effective length 220 mm 220 V 50 Hz for Europe standard
Overhang 15 mm 240 V 50 Hz for UK. & Australia standard
Tracking error 2m 110*120/220-240 V 50/60 Hz for Asia &
Adjustable force range Latin America countries
(scale) 0 7 3 g/l turn of the balance weight Power consumption 9 watts
(directly readable in 0.1 9 steps) Dimensions 435 (W) x 3751B) x 128 (H) mm
Acceptable cartridge (1771/8 x 14-3/4 x 5")
weight 4 710 9 Weight 4.5 kg (10 lbs.)
Lead Wile capacitance 140 PF Other devices Auto return, auto cut, anti-skating, tracking
AGCGSSOVY HITACHI force direct-reading balance weight, viscous
cartridge damped cueing.
Cartridge Dual magnet type (MT~30l
F EATU R ES
\
1. Smooth belt drive 4. Employment of the low center of gravity tonearm
2. Handy automatic mechanism 5. Structure resistant to howling
3. Easy-to-operate front panel controls 6. Viscous damped arm lifter never damages stylus tip
BELT nmv: TURNTABLE
April 1979
