Hitachi DVPF 2 E Service Manual
This is the 112 pages manual for Hitachi DVPF 2 E Service Manual. Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com .
Download PDF
Extracted text from Hitachi DVPF 2 E Service Manual (Ocr-read)
Page 1
CONTENTS
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . E1-1-1
LASER BEAM SAFETY PRECAUTIONS . . . . . . . . . . E1-2-1
IMPORTANT SAFETY PRECAUTIONS . . . . . . . . . . . E1-3-1
Product Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . E1-3-1
Precautions during Servicing . . . . . . . . . . . . . . . . . . . E1-3-1
Safety Check after Servicing . . . . . . . . . . . . . . . . . . . E1-3-2
STANDARD NOTES FOR SERVICING . . . . . . . . . . . E1-4-1
Circuit Board Indications . . . . . . . . . . . . . . . . . . . . . . E1-4-1
Instructions for Connectors . . . . . . . . . . . . . . . . . . . . E1-4-1
How to Remove/Install Flat Pack-IC . . . . . . . . . . . . . E1-4-1
Instructions for Handling Semi-conductors . . . . . . . . E1-4-3
PREPARATION FOR SERVICING . . . . . . . . . . . . . . . E1-5-1
How to Enter the Service Mode . . . . . . . . . . . . . . . . . E1-5-1
OPERATING CONTROLS AND FUNCTIONS . . . . . . E1-6-1
FIRMWARE RENEWAL MODE . . . . . . . . . . . . . . . . . E1-7-1
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . E1-8-1
CABINET DISASSEMBLY INSTRUCTIONS . . . . . . . E2-1-1
1. Disassembly Flowchart . . . . . . . . . . . . . . . . . . . . . E2-1-1
2. Disassembly Method . . . . . . . . . . . . . . . . . . . . . . . E2-1-1
DISASSEMBLY/ASSEMBLY PROCEDURES OF DECK MECHANISM . . . . . . . . . . . . . . . . . . . . . . . . . E2-2-1
ALIGNMENT PROCEDURES OF MECHANISM . . . . E2-3-1
ELECTRICAL ADJUSTMENT INSTRUCTIONS . . . . E2-4-1
Test Equipment Required . . . . . . . . . . . . . . . . . . . . . E2-4-1
Head Switching Position Adjustment . . . . . . . . . . . . . E2-4-1
FIXTURE AND TAPE FOR ADJUSTMENT . . . . . . . . E2-5-1
How To Use The Fixtures And Tape . . . . . . . . . . . . . E2-5-1
MECHANICAL ALIGNMENT PROCEDURES . . . . . . E2-6-1
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . E2-6-1
1. Tape Interchangeability Alignment . . . . . . . . . . . . . E2-6-2
1-A.Preliminary/Final Checking and Alignment of Tape Path . . . . . . . . . . . . . . . . . . E2-6-3
1-B.X Value Alignment . . . . . . . . . . . . . . . . . . . . . . . E2-6-3
1-C.Checking/Adjustment of Envelope Waveform . . E2-6-4
1-D.Azimuth Alignment of Audio/Control/Erase Head . . . . . . . . . . . . . . . . E2-6-4
STANDARD MAINTENANCE . . . . . . . . . . . . . . . . . . . E2-7-1
Service Schedule of Components . . . . . . . . . . . . . . . E2-7-1
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E2-7-2
EXPLODED VIEWS . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-1
Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1-1
Deck Mechanism View 1 . . . . . . . . . . . . . . . . . . . . . . . 3-1-2
Deck Mechanism View 2 . . . . . . . . . . . . . . . . . . . . . . . 3-1-2
Deck Mechanism View 3 . . . . . . . . . . . . . . . . . . . . . . . 3-1-3
REPLACEMENT PARTS LIST . . . . . . . . . . . . . . . . . . . 3-2-1
Mechanical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . 3-2-1
Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2-3 SCHEMATIC DIAGRAMS/CBAS AND
TEST POINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-1
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-3
Main 1/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-4
Main 2/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-5
Main 3/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-6
Main 4/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-7
Main 5/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-8
Main 6/8 Schematic Diagram . . . . . . . . . . . . . . . . . . . 4-1-9
Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-10
Main 7/8 Schematic Diagram . . . . . . . . . . . . . . . . . . 4-1-11
Main 8/8 Schematic Diagram . . . . . . . . . . . . . . . . . . 4-1-12
Power Supply Schematic Diagram . . . . . . . . . . . . . . 4-1-13
Function Schematic Diagram . . . . . . . . . . . . . . . . . . 4-1-14
Front Jack Schematic Diagram . . . . . . . . . . . . . . . . . 4-1-15
AFV Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . 4-1-16
Main CBA Top View . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-17
Main CBA Bottom View . . . . . . . . . . . . . . . . . . . . . . . 4-1-18
Power Supply CBA Top/Bottom View . . . . . . . . . . . . 4-1-19
Function CBA Top/Bottom View . . . . . . . . . . . . . . . . 4-1-20
Front Jack CBA Top/Bottom View . . . . . . . . . . . . . . . 4-1-21
AFV CBA Top/Bottom View. . . . . . . . . . . . . . . . . . . . 4-1-22
Junction-A CBA Top/Bottom View. . . . . . . . . . . . . . . 4-1-22
Junction-B CBA Top/Bottom View. . . . . . . . . . . . . . . 4-1-22
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1-23
DVD Main 1/4 Schematic Diagram . . . . . . . . . . . . . . 4-1-24
DVD Main 2/4 Schematic Diagram . . . . . . . . . . . . . . 4-1-25
DVD Main 3/4 Schematic Diagram . . . . . . . . . . . . . . 4-1-26
DVD Main 4/4 Schematic Diagram . . . . . . . . . . . . . . 4-1-27
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-1
Servo/System Control Block Diagram . . . . . . . . . . . . . 4-2-1
Video Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-2
Audio Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2-3
Hi-Fi Audio Block Diagram . . . . . . . . . . . . . . . . . . . . . 4-2-4
Power Supply Block Diagram . . . . . . . . . . . . . . . . . . . 4-2-5
DVD System Control Block Diagram . . . . . . . . . . . . . . 4-2-6
RF Signal Process/Servo Block Diagram . . . . . . . . . . 4-2-7
DVD Signal Process Block Diagram . . . . . . . . . . . . . . 4-2-8
DVD Video Block Diagram . . . . . . . . . . . . . . . . . . . . . 4-2-9
DVD Audio Block Diagram . . . . . . . . . . . . . . . . . . . . 4-2-10
SYSTEM CONTROL TIMING CHARTS . . . . . . . . . . . . 4-3-1
IC PIN FUNCTION DESCRIPTIONS . . . . . . . . . . . . . . 4-4-1
LEAD IDENTIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . 4-5-1
CHAPTER 1 GENERAL INFORMATION
CHAPTER 2 DISASSEMBLY AND ADJUSTMENT
CHAPTER 3 EXPLODED VIEWS AND PARTS LIST
CHAPTER 4
SCHEMATIC AND BLOCK DIAGRAMS/
CBAS
Page 2
E1-1-1
SPECIFICATIONS
Manufactured under license from Dolby Laboratories. "Dolby" and
the double-D symbol are trademarks of Dolby Laboratories.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems Inc.
CHAPTER 1 GENERAL INFORMATION
Product type:DVD/VCR player with Video Cassette Recorder
Discs: DVD video
Audio CD
Video Cassette tape
Converter output: UHF Channel 22 to 69.
Power source: 220-240V +/- 10%, 50Hz +/- 0.5%
Power consumption: 30 W (standby: 5.7 W)
Operating temperature: 5˚ C to 40˚C
Dimensions: W 17-1/8" (435 mm)
H 4" (99 mm)
D 10-1/2" (266 mm)
Weight: 8.8 lbs (4 kg)
Designs and specifications are subject to change without notice.
Page 94
4-2-3
Audio Block Diagram
RECAMP 100 3 AUTOBIAS 2
1
+5V
+5V
Q404
Q406
BIAS
OSC
Q403
N-A-PB TO Hi-Fi
AUDIO BLOCK N-A-REC
Q401 (PB=ON)
Q402
(PB=ON)
Q405
SWITCHING
D-REC-OFF
5 EQAMP 9 8
7
LINEAMP
REC-ON
AUDIO HD-SWCONTROL
MUTE 11
6
PB-ON
SP/LP-ON
P
TUNER IN2 IN1
R
ALCDET
ALC
IC301(AUDIO SIGNAL PROCESS) 15 13 17
4 A-PB/REC
CL504
3 A-COM
1 AE-H
2 FE-H
A-PB/REC 4
A-COM 3
AE-H 1
FE-H 2
CL287
AUDIOHEAD
AUDIO
ERASE
HEAD
ACE HEAD ASSEMBLY
FE HEAD
2 FE-H
1 FE-H-GND
CL501
MAIN CBA
PB-AUDIO SIGNAL REC-AUDIO SIGNAL Mode : SP/REC
71
A-MUTE-H
IIC-BUS-SCL
IIC-BUS-SDA TO SERVO/SYSTEM CONTROL BLOCK
FULL
ERASE
HEAD
68 69
SERIALDECODER
(DECK ASSEMBLY)
12
16
INV
ATT
