Page 1
CONTENTS
1. Specification -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦.-¦.1
2. Packing -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦..-¦-¦-¦3
3. Front panel information -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦...4
4. Rear panel information -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦5
5. Remote control information -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦6
6. Wiring diagrams -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
...8
7. IC spec -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦..-¦-¦9
8. Printed circuit boards -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦..-¦..41
9. Schematic diagram -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦..-¦.4\
8
10. Exploded view -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦52
11. Electrical parts list -¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦\
-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦-¦..54\
Page 2
MAS SySteM Specifications
System
Power output65 watts per channel, 20hz -“ 20khz, thd <0.07%, into 6 ohms, both channels driven
Bandwidth 20hz -“ 35kh z, -“3dB
System frequency response 20hz -“ 20kh z, ±0.5dB
Signal-to-noise ratio, a-weighted 90dB (analog inputs), 96dB (d igital inputs)
c hannel separation -‰¥65dB
c rosstalk between sources -‰¥70dB
Line-level input sensitivity at 1kh z 250mV rMS, ±1dB
Phono MM input sensitivity at 1kh z 7.5mV
Loudspeakers
Low-frequency transducers two 130mm honeycomb composite drivers, ported
high-frequency transducers two 25mm MMd
® domes, shielded
n ominal impedance 8 ohms
Sensitivity (2.83V/1m) 85dB
f requency response 60hz -“ 25kh z (-“3dB)
c rossover frequency 2200hz
FM Tuner Section
frequency range 87 -“ 108.0Mhz
u sable sensitivity Ihf 1.3µV/13.2dBf
f requency response 10hz to 15.3kh z
Signal-to-noise ratio mono/stereo 68/65dB
d istortion mono/stereo 0.15/0.3%
Stereo separation 35dB @ 1khz, 100% deviation @ 65dBf
Selectivity ±300khz; 65dBf
Image rejection 80dB
If rejection 90dB
t uner output level 1khz, ±50kh z, dev 500mV
number of presets 30
rdS capability PS (program service), rt (dynamic radio text)
0257CSK - HK MAS 101-102-111 OM v6.indd 18 08/12/10 9:44:52
1
