2TABLE OF CONTENTS
3 Introduction
4 Terminology
5 Features, Packing List
6 Front Panel Controls
7 Front Panel Information Display
8 Remote Control
10 Rear Panel Connections
11 Setup and Connections
11 to a Stereo TV and Stereo or Pro Logic
Amplifier/Receiver
12 to a Dolby Digital/DTS Amplifier/Receiver
13 to a TV or monitor with SCART or
Component Connectors
14 Remote Control
15 Digital Audio Connections
16 Playback Basics
16 Basic Play
16 Playback Features
16 About DivX Movie Files
17 System Set-up
17 System Settings
18 Audio Settings
18 Audio Adjustment
19 Video Settings
19 Video Adjustment
20 Test Screen
20 Test Screen
20 TV Picture Adjustment
21 Player Menu
21 Using the Status Bar
21 Player Menu
21 Information Displays
21 Programmed Play
22 DVD Language Codes
23 Specifications
Table of Contents
2
NOTE:This player is designed and manu-
factured for compatibility with Region
Management Information that is encoded on
most DVD discs. This player is designed only forplayback of discs with Region Code 2, or for
discs that do not contain Region Code infor-
mation. If there is any other Region Code on a
disc, that disc will not play on the DVD.
Declaration of Conformity
We, Harman Consumer Group International
2, Route de Tours
72500 Château-du-Loir,
FRANCE
declare in own responsibility, that the product described in
this owners manual is in compliance with technical
standards:
EN 55013:2001
EN 55020:2002
EN 61000-3-2:2000
EN 61000-3-3:1995+A1:2001
EN 60065:2002
Jurjen Amsterdam
Harman Consumer Group International
10/05
Page 2
INTRODUCTION 3
Introduction
Thank you for choosing the
Harman Kardon DVD
The DVD is a multipurpose DVD player, capable
of playing both DVD-Video discs and convention-
al CD audio discs with the highest fidelity and
access to future software upgrades via the
Internet. Along with conventional Video and CD
audio discs, the DVD 23 is also compatible with
MP3, CD-R and CD-RW as well as DivX
®and
VCD discs.
To enable you to get the maximum quality from
DVDs, the DVD is equipped with the latest in
design techniques, including advanced 10-bit
video digital-to-analog converters (DAC) and
Video (composite), S-Video and RGB video (RGB
via SCART) outputs, to ensure that you get all the
quality inherent in todays DVD medium.
For optimum playback of NTSC and PAL DVD
with compatible high-definition display devices,
DVD is equipped with progressive component
video outputs.
In addition, Harman Kardons audio heritage
continues into the digital video era with audio-
phile-grade Wolfson DACs to ensure that the
audio quality matches the superb video. Of
course, both coaxial and optical digital audio
outputs are available for direct connection to A/V
receivers or processors so that you may take
advantage of Dolby Digital* and DTS
®sound-
tracks. When playing audio CDs, the playback
quality is state-of-the-art, matching that of the
finest players available.A wide range of programming features makes it
easy to program an evenings worth of entertain-
ment. When playing DVDs, easy-to-understand
on-screen menus and icons make it simple to
change languages, soundtracks, subtitles or
aspect ratio.
DVD players are among the fastest growing
consumer electronics products ever brought to
market, but this may, nevertheless, be the first
DVD player youve owned. Although many of the
features of the DVD resemble those of standard
CD players, there are a number of functions that
you may be unfamiliar with. To ensure that you
are able to take advantage of all the power and
flexibility the DVD has to offer, we encourage you
to review this quick setup manual. That small
investment of your time will pay major dividends
in the enjoyment you will get from proper use of
the DVD.
If you have additional questions about this
product or its installation or operation that are
not answered in this manual, please contact your
dealer, as he is your best source of local infor-
mation.Plays a Wide Range of Video and Audio
Formats, Including DVD-Video Discs,
VCD, Standard CD Audio Discs, CD-R/RW,
DVD-R/RW, DVD+R/RW, Audio Discs and
MP3 Discs
High-Quality Video Playback 10-Bit
DACs, Progressive Scan and Component
Video Outputs
Dolby Digital and DTS Data Signal
Output Through Both Optical and
Coaxial Digital Audio Connections
Audiophile-Grade Wolfson Output DACs
for the Finest Audio reproduction
Easy-to-Use On-Screen Navigation
System
Playback of MP3 and Windows
®WMA
Audio Discs and JPEG image files
Simultaneous Playback of MP3 and
JPEG files
Playback of DivX compressed video
files.
Extensive Programming Capability for
Audio and Video Discs
Multiple Options for Language,
Soundtrack and Subtitle Selection
Multiple-Angle Capabilities With
Specially Encoded DVD Discs
Backlit, Ergonomically Designed
Remote Control
