Extracted text from Hafler SE 240 Owners Manual (Ocr-read)
Page 1
SPECIFICATIONS
Power Rating:
Less than 0.025% total harmonic distortion at any
power level up to 120 watts continuous average power
per channel into 8 ohms at any frequency between 20
Hz and 20
kHz with both channels driven,
Continuous Power Output:
Into 4 ohms, below -04% THD, 20 Hz-20 kHz,
per channel: 175 watts
IM Distortion (IHF):
Less than 0.005% from 1 watt to 120 watts, each
channel, into 8 ohms.
Typical THD at $0 watts into 8 ohms:20
Hz: 0.004%
1 kHz: 0.004%
20 kHz: 0.02%
Frequency Response into 8 ohms:
-3
dB, 2 Hz to 200 kHz at 1 watt.
+0 dB, -0.5 dB, 4 Hz to 40 kHz at 120 watts.
Typical Channel Separation:
20 Hz: 80 dB
1 kHz: 75 dB
20 kHz: 60 dB
Signal to Noise Ratio:
Exceeds 100 dB referred to 120 watts into 8 ohms.
Page 2
Input Impedance:
47,000 ohms.
Input Sensitivity:
1.2 volts rms for 120 watts into 8 ohms.
Slew rate:
10 kHz, 60 volts peak to peak square wave: 45 v/us
Damping Factor:
300 to 1 kHz into 8 ohms.
200 to 10
kHz into 8 ohms.
Power consumption:
120 watts both channels into 8 ohms: 550 VA
Quiescent: 120 VA
Size:
5-1/4 high plus 1/2 feet, 17 wide. and 10-1/2 deep.
Net Weight:
27 Ibs.
Shipping Weight:
31 Ibs.
All specifications are subject to change without notice.
2
