Page 1
It is a good habit to turn down BOTH remote and main
panel volume controls upon system shut-down. This
will avoid possible sudden and unexpected changes in
volume when system is re-activated.
TABLE OF CONTENTS
Introduction .................................................................Page 1
installation .................................................................. Page 2
Operation .................................................................... Page 5
IRIS Block Diagram .................................................... Page 7
Using the IRIS Remote System
Introduction ............................................................... Page 10
Operation
................................................................. Page 14
Specifications
........................................................... Page 16
Warranty
................................................................... Page 18
INTRODUCTION
Your IRIS preamplifier combines superb, all-discrete, J-FET
amplification stages with unique control methods allowing
unprecedented flexibility and convenience. In this manual,
beyond telling you how to use IRIS, we will try to convey the
spirit and method of how this unusual combination was achieved.
The J-FET devices share many technical and sonic charac-
teristics with the best of vacuum triodes. They also allow things
vacuum tubes don't easily allow, such as high speed and very
low noise.
Page 2
INSTALLATION
The gloss black insert on the face-plate of your new HaflerEquipment has been packaged with a removable protective
coating. Please peel off this protective coating following in-
stallation.
When cleaning the face-plate, we advise a soft cotton cloth with
a non-abrasive cleaner that is safe for lexan and painted
surfaces. DO NOT use paper towels or any coarse material to
clean the face-plate as these materials may scratch the insert.
IRIS is shipped with styled end caps on its front panel. Rack-
mounting ears are available from the factory for standard 19-
wide racks. In locating IRIS, keep these factors in mind:
1) All preamplifiers with high-gain moving-coil phono circuitry
can be susceptible to pickup of hum from strong external
magnetic fields. Such fields are usually strongest from power
amplifiers, but can also come from other equipment. When
stacking or racking your equipment, you may have to do so as
to minimize this potential problem.
2) The
IR (infrared) eye for the IRIS remote system is behind
the dark red screen above the Record 1 switch. The IRIS remote system combines a powerful transmitter and very
sensitive receiver, resulting in highly reliable communication
under conditions where many remotes will not work. However,
best operation usually results if the preamplifier is located AT or
ABOVE the height at which you will typically use the transmitter.
3) It is also desirable that the IR eye not have to look directly
at extremely bright light sources, particularly those of fluores-
cent nature. Such conditions can impede communication reli-
ability.
