Allgemeiner Tail / General Section
STFI 6000
Es gelten die Vorschriften und Sicherheitshin-
weise gemaB dem Service Manual "Sicherheit",
Materialnummer72010 800 0000, sowie zusatz-
lich die eventuell abweichenden, landes-
spezitischen Vorschriften!
The regulations and safety instructions shall be
valid as provided by the Safety" Service Manual,
part number 72010 800 0000, as well as the
respective national deviations.
® lnhaltsverzeichnis
Allgemeiner Teil ..
MeBgerate / Hiltsmittel 1 - 2
Technische Daten ...... .. 1 - 2
Bedienhinweise ......................................................................... 1 - 3
Schaltplane und
Druckplattenabbildungen.
Schaltplan Netzteil ............................
Gesamtschaltplan .........
Druckplattenabbildungen
1...3-2
Ersatzteilliste................................. 3 -
Allgemeiner Teil
Messgerate / Messmittel
Beachten Sie bitte das GRUNDIG Messtechnik-Programm, das Sie
unter Iolgender Adresse erhalten:
Table of Contents
General Section ..
Test Equipment/Aids 1- 2
Technical Data ...... 1 - 2
Operating Hints ......................................................................... 1 - 8
Circuit Diagrams
and Layout of PCBs .. 2 -1 .2 - 12
Circuit Diagram Power Supply ..
General Circuit Diagram .
Layout of PCBs
1...3-2
Spare Parts LIst 3 -
General Section
Test Equipment / Aids
Please note the Grundig Catalog "Test and Measuring Equipment"
obtainable from:
GRUNDIG Instruments Test- und Messsysteme GmbH
Wiirzburger Str. 150, D 90766 FflrthlBay
Tel. 0911/703-4118, Fax 0911/703-4130
eMail: instruments@grundig.de
Internet: http:I/www.grundig-instruments.de
Technische Daten
Programmplatze: ................................................................................ 299
Audioteil
Frequenzgang (DIN 45500):
Tonuntertrageflrequenz
Deemphas
Bandbreite
.2.0-Hz 15kHZ
Einstellbarm von ...5 0 bis 9, OMHZ
Emptang
Frequenzband:
Eingangsniveau.
EingangsbandbreIte
Demodulator:
Schnittstelle zur Satellltenantenne
Eingang:
LNB-Spannung
Pclarisatcrsteuerun .
Schaltsignal: ..........
..AnschluB vorn Typ »F«
.OV/ 14V / 18V (SOOmA)
Typ )IMARCONM (14/18)
....... 22kHZ (ElN/AUS)
Verschiedenes
Stromversorgung'
Energieverbrauch
230V~ / 50Hz
S 40W
< 15w Standby
Bruttcgewichtzu ............................................................ 3kg
Abmessungen (H x B x T). .......................................... 72 x 365 x 230mm
Anschliisse
.. Eur0»AV-AnschluB
Euro-AV-AnschluB
.. Euro-AV-AnschluB
Cinchstecker (RCA)/Iinker und rechter Kanal/SOO mV
. Kanale 30 bis 45 einstellbar/eingestellt auf Kanal 43
Eingang terrest he Antenne ..
Ausgang terrestrische Antenne
Technical Data
Programme positions: ........................................................................ 299
Audio Unit
Frequency response (DIN 45500):
Subcarrier Irequencie
De»emphasi
Bandwidth: .
.................. 20HZ - 15kHz
Tunable from 5.0 to 9.0MH2
50us, J17, 75p.s
130/280kHz
Reception Unit
Frequency band
Input level: ..
Input bandWIdth.
Demodulator:
920-2050MH2
Satellite aerial Interface
Input:
LNB voltage
Polarisation comman .
Switching tone:
.....Type >>FI< connector
OV/ 14V / 18V (SOOmA)
»MARCONI type<< (14/18)
......... 22kHz (ON/OFF)
Miscellaneous
Power supply .230V~ / 50Hz
Consumption: .. S 40W
< 15W stand-by
Gross weight: ...................................................................................... 3kg
Dimensions (H x W x D): ............................................. 72 x 365 x 230mm
Connections
Euroconnector
Euroconnector
Euroconnector
. Cinch (RCA) plug / left and right channels/ 500 mV
. Tunable from 30 to 45 / set on channel 43
IEC socket
lECplug
terrestrial aeria p
terrestrial aerial output
1-2
GRUNDIG Service
