Page 1
2
22 2
~ÄëçäìÃÉ=ÑáÇÉäáÃó-„¢
A Message from Genesis
Congratulations! You are now the owner of one of the finest sub-
woofers available for music and home theater systems.
The Genesis Surround ServoSub-„¢ 2/12t is a unique subwoofer with
two 12 woofers that is designed for applications requiring corner or
sidewall placement, and is universally installation friendly. The unique
shape of the S2/12t makes it an ideal partner to surround or rear
loudspeakers in a multi-channel music or home theater system. The
S2/12t is ideal in multiple subwoofer installations where the distributed
bass of the system produces low bass that is more even, without
resonance peaks (nodes) and valleys (anti-nodes) of a single source.
The S2/12t delivers bass frequencies as intended by the musical
performer, or as intended by the movie director. This is what we call
absolute fidelity-„¢. In this case, we mean that the bass response of
the speaker is completely faithful to the input signal. This is achieved
by servo control of the woofer cone.
The S2/12t plays as loudly and deeply as much larger sub-woofers
that cost much more, and outperforms them in terms of transient
fidelity and freedom from the colorations inherent in ported subwoofer
designs.
Robert Harley puts it best in his review of the Genesis subwoofers in
The Perfect Vision: Transient impact was extraordinary; the dynamic
envelope of low-frequency sounds was tight, clean, and articulate-¦. In
addition, bass extension was outstanding; this woofer extended to
subterranean depths and maintained its composure. He went on to
say, It combines first-rate musicality and exceptional delicacy with a
bottom-end solidity and power that was fully up to the job of
reproducing todays dynamic soundtracks.
Please read through the Owners Manual and Set-up Guide to achieve
the maximum enjoyment from your purchase.
Please write the serial number and purchase details of your Genesis S2/12t
here for future reference.
Purchased at: _________________ Date: __________
Page 2
3
33 3
~ÄëçäìÃÉ=ÑáÇÉäáÃó-„¢
A Quick Star t Set-up Guide
Now that you have your new Genesis Surround ServoSub 2/12t, we
realize that you are eager to hook it up and start listening!
Nevertheless, please read this quick start guide NOW before you
begin setting it up.
Safety Tips
The S2/12t is a powered subwoofer with a built-in amplifier: it needs to
be connected to a power socket that is always on. Make sure that you
are providing the correct voltage, and keep the S2/12t away from water
and direct heat.
Connections
There are two common options for hooking-up
the S2/12t to your existing system. For
dedicated music systems and bass extension
of surround speakers, connect the high-level
speaker binding posts on the S2/12t to your
amplifiers speaker outputs, or connect them
to the speaker through binding posts on the
associated speaker, using a short run of
loudspeaker cable.
For traditional subwoofer use in audio/video
systems in multi-channel home theater
applications, connect the line level LFE output
of your processor to the LFE input on the
S2/12t
Our unique LFE Blend-„¢ technology allows
you to use the S2/12t in BOTH your music
system and your home theater system at the
same time by using the high-level speaker
inputs to augment the bass response of your
surround speakers and connecting your
processors LFE output to the the LFE Input.
You are able to blend the two signals together
for better bass management of your listening room.
The S2/12ts LFE out can be used to daisy-chain multiple Genesis
subwoofers together for better control of the bass modes in your
listening room. This makes bass management easier, and reduces the
chance of experiencing a boomy, inarticulate bass response.
