Gas son of ampzilla owners manual

Page 2

JWER OUTPUT _
4 OHMS Minimum 150 Watts per channel, both channels driven, 20 Hz to 20 KHz
8 OHMS Minimum 80 Watts per channel, both channels driven, 20 Hz to 20 KHz

l6 OHMS Minimum 50 Watts per channel, both channels driven, 20 Hz to 20 KHz
[Industrial rack-panel mount version provides 250 Watts per channel at 2 Ohms)

OTAL HARMONIC DISTORTlON 8: LM. DISTORTION

4, 8, 8: 16 OHMS Less than 08% at any frequency or combination of frequencies,
and at any power level to clipping.

llPUT SENSITIVITY 1.0 Volts R.M.S. for 80 Watts into 8 Ohms.

\IPUT IMPEDANCE 75K Ohms

iBOSSOVER NOTCH -- NON EXISTENT
:REQUENCY RESPONSE (Power Bandwidth) at rated power or any level less than rated power.
8 8c 16 OHMS Better than i0.1 dB. 20 Hz to 20 KHz
Better thanil dB, 1 Hz to 100 KHz

iISE TIME AT 8 OHMS Better than 21.: seconds. AT FULL POWER AT 20 KHz.
Slew rate equal to 40 Volts per second.

iEAT-SINK DIMENSION

if DUTY CYCLE Over 1000 sq. in. total, providing continuous operation at ambient temperatures
up to 125° F.

STABILITY 100% stable into any load angle 0° to 90°, capacitive or inductive, regardless of

waveshape - sine, square. or triangular..No oscillations or modulation noise evident.

OVERLOAD PROTECTION & FUSING:
Trensistorized dynamic short-circuit protection. Thermal breaker also protects

against overheating, 4 B+, 3- power supply fuses, l AC slow-blow power fuse.

NOISE Better than 100 dB below full power (unweighted, wide band). 112 dB below ful'
power (wide band with Rf. filter).
SIZE: Std; 16%" (W) x514 (H) x 11" (D).

BIk. Panel: 17" (W) x 5%" (H) x 11" (D).
Rack Punei: 19 (W) x 5%" (H) x 12" (D).

SHIPPING WEIGHT: 25 lbs.
