Garrard 4HF Owners Manual

Page 1

SINGLE RECORD
PLAYING UNIT

MODEL 4HF

OPERATING INSTRUCTIONS

43%

THE GARRARD ENGINEERING AND MANUFACTURING CO. LTD. - SWINDON ~ WILTSHIRE - ENGLAND

Page 2

THE GARRARD MODEL 4HF

SINGLE RECORD PLAYING UNIT

The Garrard Model 4HF Unit is a Single Record Playing Unit designed and manufactured
to the high standard which is synonymous with the name of Garrard.

In common with all other Garrard equipment, it is simple and reliable in operation. Extreme
accuracy in the machinin of components and delicacy of pivots combine to produce a unit
which is as free from ow, Flutter and Rumble as it is possible to achieve.

It is wired for Stereophonic Reproduction, and the Plug-in Pickup Head Moulding
will accommodate any Garrard Pickup Cartridge and most of those of other manu-
facturers including Stereophonic models.

Instructions are given in this manual for installing and operating the unit, but in the case of
further information being desired, our Technical Service Department will gladly assist
you. In any communication re arding this unit, please quote Model number, Schedule number
and type of Pickup Cartridge fitted. The two former will be found on the small square plate
at the rear of the Unit and the latter is on the Pickup Cartridge itself.

Address your enquiries to:- The Garrard Engineering & Mfg. Co. Ltd,
Technical Service Department.
Newcastle Street, Swindon, Wilts.

Telephone No.: Swindon 5381 (5 lines).
Telex: 44271.

If you wish to make enquiries concerning the return of a Unit for repair, or if you require spare parts,
address your letter to:- The Garrard Engineering & Mfg. Co. Ltd,
Service and Spares Department,
Radnor Street, Swindon, Wilts.

Telephone No.: Swindon 22606.

Page Two

Page 10

TAG STRIP FOR CATCH LEVER HOUSING FOR
PICKUP CONNECTION SPRING TURNTABLE SPINDLE
I

LIFTING GEAR
FOR SPEED CHANGE

PICKUP REST
RETURN SPRING

VOLTAGE AND
REQUENCY RANGE
monomo ON
/ MOTOR END cover:
awe LEVER ./

PRIN
S G \ EARTHING TAG

ON MOTOR

TERMINALS FOR
\ CONNECTING
POWER SUPPLY

\ UNDER COVER
'\
SWITCH CLICK INDEX LEVER
SUPPRESSOR SPRING
Diagram 4
