Garrard 35 SB Owners Manual

Page 2

Page 2 Introduction

Page 3 Futures and specifications
Page 4 Installation

Page 5 Installation adjustments
Page 6 Wiring connections

Page 8 Operating instructions

Page 10 Fitting pickup cartridge
Page If Garrard module base and cover
Page 12 Maintenance

Page 14 Adjustments

Page 15 Sales service

The information in this booklet most likely to be
needed is arranged in the first sections. The later
sections may be referred to as required. Those
owners who have purchased Model 3588 in a
ready mounted module form or already installed
in a cabinet to which only lead connections are
required. may ignore most of the installation
sections in this booklet. However, it is advisable
to check that the stylus force and bias
compensation are set to suit your pickup cartridge
before using the unit. also that the unit is correct
for the power supply. particularly if it is a

dual- voltage unit.

Over the years. to many people the name Garrard has become
synonymous with high fidelity record playing equipment. Yet
Garrard have always recognised that although attention to quality
has gained this select reputation. in the audio world as in any other.
the laws of diminishing returns on performance apply. as
expenditure increases.

This value for money problem is overcome by Garrard in offering a
choice of quality products, from turntables made to basic agreed
standards to more sophisticated products with extra performance
and extra features. Within this range. Garrard have found that
customer demand confirms the laws of cost-engineering and with
Model 3588 is introduced a single record playing unit made to the
specifications and with features which have made its predecessors
such an outstanding success in their category.

The refinements which justify this new model are listed opposite
together with some of the features which have proven so popular
with this class of unit.

Modelvarfents

Model 3558 may be supplied as a deck or as a module or incorporated with
other equipment. such as in a music centre. The type of leads or connectors
fitted may be tailored to suit these requirements or partiCuIar territories.
Because of these requirements and other variables. for example. cartridge type
or special trims. Model 3558 may differ in some details other than as

portrayed. The basic specification of the unit is not affected by any such
changes.

Safety regulation note for USA models

WARNING: To prevent fire or shock hazard. do not expose this
appliance to rain or moisture.

-
2-

Page 3

features

Features and Specifications

. Single record playing unit, with automatic lacility by pre-selection

of speed (33', rev/min or 45 rev/min) and record size (7in. 10in
or 12in).

0 Automatic repeat control and manually operated replay control.

C Switches off with pickup arm in rest position after manual or
automatic play. unless overridden by 'Repeat' control.

C Belt-drive turntable. effectively non-magnetic.

0 Precision engineered tubular pickup arm with decoupled
counterbalance weight.

0 Removable slide-in cartridge carrier accepts a wide range of
cartridges.

C Damped cue and pause lacility with line control.
Diagram 1

O Garrard Synchro-Lab motor.

0 Available with Garrard base and cover.

Technical Specification

Wow and flutter 0.20 peak % max. (DIN).
Rumble -55d8 (DIN 8).
Minimum stylus force Hg.

3

Page 13

Service hints

The relerencos below may be ol use as a check list.
Pickup mistrecking: A. B. C. 0. E. F

Distorted sound: A. B. C. O. G. K

Speed varies: H. J

A Check stylus is clean

KEY
18.1
18.2
83
18.4

Check stylus is correct type lor record being played

Check that back ol cartridge or leads do not touch record - fit tilt wedge it
necessary

Check balance ol pickup arm. stylus lorce and bias compensator setting
Check pickup leads not caught up. restricting arm movement at rear
Check cue and pause control in down position

Have amplifier and loudspeakers checked

Check no oil on motor pulley. drive belt or turntable drive drum

Check belt lilting guide not rubbing top or bottom ol drive belt

ll low hum allects sound. check earthing arrangements lor your hi-fi
system

Lilting guide adjustment screw
Drive belt with identification stripe
Lilting guide

Motor pulley

13
