SPECIFICATIONS
Conditions:
1. 0 dBu-OJ75 V rms.
2. Dual-mode ratings are for each channel.
3. Both channels operating at rated output
power unless noted.
4. 120-voit ac line Input voltage maintained
(or all tests unless noted.
Continuous noted Output Power
(20 Hz - 20 Hi: at less then 0.1% THD),
Dual Mode, an:
200 wattslch
Bridge Mode, BIZ:
400 watts
Duel Mode, on:
125 wattsleh
Bridge Mode, 160:
250 watts
Continuous Rated Output Power to
Subwooier (20 Hz - 1 kit: It In: then
0.17. THD),
Duel Mode, an:
215 wattsleh
Bridge Mode. an:
435 watts
Dual Mode. an:
130 watts/ch
Bridge Mode. 16):
265 watts
Maximum Midhend Output Power
(reterence 1 kHz. 1% THD,
G 120 volts ec line voltage),
Duel Mode, 40: >230 watts/ch
Bridge Mode, an: >465 watts
Duel Mode, 0!}: >140 watts/ch
Bridge Mode. 161}: >285 watts
(reierenoe 1 kHz, 1% THD,
6 103 volts no [10% seal).
Duel Mode. 402 >185 watts/ch
Bridge Mode, an: >370 watts

Duel Mode. an: >110 watts/ch
Bridge Mode, 169: >220 watts
(reterence 1 kHz. 1% THD,
0 100 volts u: (17% sagl).
Duel Mode, 411: >155 watts/ch
Bridge Mode, 8D: >310 watts
Duel Mode. an: >95 watts/oh
Bridge Mode, 160: >190 watts
Headroom (Before clip):
(reference 1 kHz, 19. THD),
Single Channel Mode:
31 dB
Power Bendwidttl
(reference 1 kHz. +0.4 dBr where 0 dBr -
reted output power In my mode),
20 Hz - 20 kHz
Frequency Response
(reierence 1 kHz, 1 wett output, +0, -3 dB):
10 Hz - 50 kHz
Voltage Geln (reterence 1 kHz),
Duel Mode, An:
31 dB
Duel Mode, 89:
32 dB
Bridge Mode. 80:
37 dB
Bridge Mode, 169:
38 dB
Input Sensitivity tor Hated Output Power
(reference 1 kHz. 20.5 dB),
Duel Mode, an:
0 d8 (0.78 V rms)
Bridge Mode, 80:
-0.25 dBu (0.78 V rms)
Duel Mode. an:
+0.5 dBu (0.89 V nns)
Bridge Mode, 160:
+0.5 dB(0.89 V rms)
Maximum Input Level (reverence 1 kHz):
+20 dBu (7.75 V rms)

EbeMflbbe

JMARK IV

7200

Two-Channel
Power Amplifier

Input impedance
(reference 1 kHz),
Bel-need:
>30 kn
Unbeienced:
>15 kn
Phase Response
(It rated output power. eny mode).
It 20 Hz:
< 4.30"
at 20 kHz:
> .30"
THD (Any mode, 30 kHz measurement
bandwidth):
<0.1% (Typ. <0.01%)
IMD [SMPTE 4:1] (Any mode):
<0.1% (Typ. 41.01%)
Slew Flute (It rated output power),
Duel Mode, 4 or 0 (1:
>20 Vlusec
Bridge Mode. 8 or16 {1:
>25 V/usec
Dumping Fector,
Duel Mode, an,
1 kHz: >100
Nolle (below reted output power, A-
welahting tilter, any mode, 50/60 Hz no line
irequency):
>100 dB
Amplifier Protection:
Shortened output terminals
Over tam parature
RF inteierenoe
Load Protection:
Startup/shmdown transients
DC faults
Subsenic signals
Cooling,
Heatslnlc
Convention black heatsink
