Page 1
2
\frep\br\btion
MOUNTING SLEEVE
REMOVAL KEYS
TY\fICAL-ˆ FRONT-LOAD-ˆ DIN-ˆMOUNTING-ˆ METHOD
XR4115-ˆINSTALLATION
Please read entire manual before installation.
Before-ˆYou-ˆSt\brt
- Disconnect negative battery terminal. Consult a qualified technician for instructions.
-
Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting-ˆ St\brted
-
Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
-
Install mounting sleeve into opening, bending tabs to secure.
-
Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
-
Certain vehicles may require an installation kit and/or wiring harness adapter (sold
separately).
-
Test for correct operation and slide into the mounting sleeve to secure.
-
Snap trim ring into place.
Page 2
3
10 AMP
AGC Fuse
Rear RCA Output
Antenna Connector
Right (Red)
Left (White)
Wiring-ˆ Di\bgr\bm
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio. The
XR4115 uses one 10 amp
AGC fuse located in-line.
XR4115-ˆ INSTALLATION
