Page 1
2
TYPICAL-ˆFRONT-LOAD-ˆ DIN-ˆMOUNTING-ˆ METHOD
Please read entire manual before installation.
Before-ˆYou-ˆStart
-
Disconnect negative battery terminal. Consult a qualified technician for instructions.
-
Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting-ˆStarted
- Remove trim ring from unit,
- Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
- Install mounting sleeve into
opening, bending tabs to secure.
- Connect wiring harness and
antenna. Consult a qualified
technician if you are unsure.
- Certain vehicles may require an
installation kit and/or wiring
harness adapter (sold separately).
- Test for correct operation and slide
into mounting sleeve to secure.
- Snap trim ring into place.
XML8110 -ˆINSTALLATION
Preparation
KE YS
HEX BOLT
MOUNTING SLEEVE PLAIN
WASHER
HEX NUT
MOUNTING STRAP
Page 2
3
FUSE
When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XML8110 uses one10 amp ATM fuse located beside the wiring connector.
XML8110-ˆ INSTALLATION-ˆ
Wiring-ˆ Diagram
Antenna
Connector
REAR/SUB Preamp Output
(selectable)
RCA Preamp Connections
FRONT RCA Preamp Output
Steering Wheel Interface Input
(PAC SWI-PS required )
BLACK 8-pin Female Mini-DINBTM60 Connection (sold separately)
RCA Auxiliary Inputiplug-„¢ Connection
GREEN 8-pin Male Mini-DINExternal Accessory Connectio n
