Page 1
2
TYPICAL-ˆFRONT-LOAD-ˆ DIN-ˆMOUNTING-ˆ METHOD
Removal Keys
Head Unit
Mounting Sleeve
Dashboard or Installation Kit
XDMA6438-ˆINSTALLATION
Preparation
Please read entire manual before installation.
Before-ˆYou-ˆStart
- Disconnect negative battery terminal. Consult a qualified technician for instructions.
-
Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting-ˆ Started
- Remove trim ring from unit.
- Remove 2 transit screws located on top of the unit.
- Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
- Install mounting sleeve into opening, bending tabs to secure.
- Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
- Certain vehicles may require an installation kit and/or wiring
harness adapter (sold separately).
- Test for correct operation and slide into
mounting sleeve to secure.
- Snap trim ring into place.
Page 2
3
XDMA6438-ˆINSTALLATION-ˆ
Wiring-ˆDiagram
Rear RCA InputConnect a portable device
Antenna InputConnect the vehicle antenna
FUSE
When replacing the
fuse, make sure new
fuse is the correct type
and amperage. Using
an incorrect fuse could
damage the radio.
The XDMA6438 uses
one 10 amp ATM fuse
located beside the wiring
connector.
