Page 1
2
TYPICAL-ˆFRONT-LOAD-ˆ DIN-ˆMOUNTING-ˆ METHOD
MOUNTING SLEEVE
REMOVAL KEYS
XDMA6370 -ˆINSTALLATION
Preparation
Please read entire manual before installation.
Before-ˆ You-ˆStart
-
Disconnect negative battery terminal. Consult a qualified technician for instructions.
-
Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting-ˆStarted
- Remove trim ring from unit,
- Remove 2 transit screws located on top of the unit.
- Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
- Install mounting sleeve into opening, bending tabs to secure.
- Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
- Certain vehicles may require an installation kit and/or wiring
harness adapter (sold separately).
- Test for correct operation and slide into
mounting sleeve to secure.
- Snap trim ring into place.
Page 2
3
FUSE
When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XDMA6370 uses one 10 amp ATM fuse located beside the wiring connector.
XDMA6370 -ˆINSTALLATION -ˆ
Wiring -ˆDiagram
REMOTE N
FRONTR /SUB AUX
R CH LCH
Antenna
Connector
Steering Wheel Interface Input (PAC SWI-PS required)
REAR/SUB(selectable)
RCA Preamp Connections
FRONT AUX INPUT (rear)
