Page 1
2
XDM6351 -ˆINSTALLATION
TYPICAL-ˆ FRONT-LOAD-ˆ DIN-ˆMOUNTING-ˆ METHOD
REMOVAL KEYS
MOUNTING SLEEVE
INSTALLA TION
MOUNTING KIT
OR DA SHBOARD
XDM6351 HEAD UNIT
Preparation
Please read entire manual before installation.
Before-ˆ You-ˆStart
-
Disconnect negative battery terminal. Consult a qualified technician for instructions.
-
Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting-ˆStarted
- Remove trim ring from unit.
- Remove 2 transit screws located on top of the unit.
- Insert the supplied keys into the slots as shown, and slide the unit out of the mounting
sleeve.
- Install mounting sleeve into opening, bending tabs to secure.
- Connect wiring harness and antenna. Consult a qualified technician if you are unsure.
- Certain vehicles may require an installation kit and/or wiring
harness adapter (sold separately).
- Test for correct operation and slide into
mounting sleeve to secure.
- Snap trim ring into place.
Page 2
3
XDM6351 -ˆINSTALLATION
Wiring-ˆ Diagram
Antenna
Connector
Rear RCA Preamp OutputConnect to an amplifier input
10 AMP
AGC Fuse FUSE
When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XDM6351 uses one10 amp AGC fuse located in-line.
