Page 1
2
XDM6220 INSTALLATION
Preparation
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Please read entire manual before installation.
Before You Start
- Disconnect negative battery terminal. (consult a qualified technician for instructions)
- Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
- Remove 2 transit screws located on top of the unit.
- Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
- Install mounting sleeve into
opening, bending tabs to secure.
- Connect wiring harness and
antenna. (consult a qualified
technician if you are unsure)
- Certain vehicles may require an installation kit and/or wiring
harness adapter (sold separately).
- Test for correct operation and slide into mounting sleeve to secure.
- Snap trim ring into place.
- Mount the iplug-„˘ adapter to any
smooth clean surface using the
supplied double-sided tape or
#2 x 3/8 Phillips head screws.
Page 2
3
XDM6220 INSTALLATION
Wiring Diagram
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio. The
XDM6220 uses one 10 amp
AGC fuse (Battery) located
in-line.
