Dual XC 4100 Owners Manual

This is the 8 pages manual for Dual XC 4100 Owners Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 8
left right
Dual XC 4100 Owners Manual

Extracted text from Dual XC 4100 Owners Manual (Ocr-read)

Page 1

KEYS XC4100INSTALLATION Preparation Please read entire manual before installation. "#  $- Disconnect negative battery terminal. (consult a qualified technician for instructions) - Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. %!&'-Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve. -DIN mounting procedure: Install mounting sleeve into dash opening, bending tabs to secure. -2-Shaft mounting procedure: Remove knobs, faceplate and DIN mounting adapters from unit. Install unit into kit or dash opening from behind. Adjust rear shaft nuts to correct depth. Install faceplate and knobs. -Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately). 2

Page 2

KNOBSSHAFT NUTS MOUNTING SLEEVE DIN ADAPTERS DASH OPENING OR INSTALLATION KIT KNOBS SHAFT NUTS XC4100INSTALLATION Installation 3 Typical 2-Shaft Mounting Typical DIN Mounting
