LU43P-LU53PINTRODUCTION
Introduction
The DUAL outdoor speaker series is designed as a multi-
purpose speaker and will deliver accurate high fidelity sound
in exterior or interior environments. Weather-resistant design
and construction provide optimum durability for permanent or
temporary outdoor use. Both models are available in black
or white.
For simplicity, we will call your AV receiver or amplifier
the receiver.
The grilles are not designed or intended to be removed. Do
not remove the grilles from your speakers. There are no user-
serviceable parts behind the grille and removal will damage
the speaker.
You must have proof of purchase to receive warranty service.
Please keep your original sales receipt and be prepared to
provide this receipt in the event you require service, as your
original receipt is considered the best proof of purchase and
indicates the date you purchased your Dual product.
Model
Dealer Name
Dealer Phone
Purchase Date
Note: You may want to keep your original sales receipt or a
photo copy with this installation/owners manual. Introduction
Important
Warranty Coverage
For Your Records
®
Page 2
Recommended minimum distance
between speakers
(610)
3
LU43P-LU53PPLACEMENT
Speaker Placement
If mounting is desired, mounting both speakers on a
common solid surface facing the listening area will provide
the best audio results.
Do NOT mount speakers on wall surfaces that have hazards
concealed behind them, such as electrical wires or
plumbing. Always mount speaker on surfaces that are
sturdy enough to support the speakers weight, and make
sure they cannot fall or cause injury.
Your speakers can be placed in many convenient locations
in your home or patio area - as stereo pairs on either side
of your receiver - as surround speakers in home theater
surround sound systems - in your computer room to
enhance the multimedia experience - or as remote
speakers.
For wall and ceiling applications, DUAL mounting brackets
are included. In addition, the LU43 has a rear inset keyhole
for surface hanging, and the larger LU53 has two 1/4-20
brass inserts incorporated into the rear of the enclosure if
aftermarket mounting systems will be used.
You should experiment with various placements. Room
acoustics can produce large apparent differences in the
sound when small changes in the placement are employed.
For example, although the speaker may be located at any
height above the floor, directing the tweeter toward ear level
(32" -“ 36") or angling the entire speaker toward the listening
position often provides the most realistic imaging
experience. The amount of bass perceived increases as you
move a speaker closer to solid intersecting room surfaces
(walls, ceiling, floor). Mounting Placement
Speaker Placement
Wall and Ceiling
Placement
Experiment for Better
Sound
®
