Page 1
2
DS-ˆSERIES-ˆ PREPARATION
Getting-ˆStarted
Safety
This symbol is intended to alert the user to the presence of
important instructions. Failure to heed these instructions
can result in injury or unit damage.
To prevent injury and damage to the unit, please read and follow
the instructions in this manual.
If you feel unsure about installing this system yourself, have it
installed by a qualified audio technician.
Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Thank you for purchasing the DS Series car speakers. Although Dual has attempted to
make sure all of the information contained within this manual is accurate, please be
aware that any part of it is subject to change without notice.
Page 2
3
DS-ˆSERIES-ˆ INSTALLATION
Installation
The following installation instructions are very basic. If you feel unsure
about personally installing this speaker system, Dual recommends
acquiring the services of a professional car audio installation center.
Before-ˆ installation,-ˆ please-ˆfollow-ˆthese-ˆguidelines:
1. Be sure to carefully read and understand the instructions before attempting to install this product.
2. For safety, disconnect the negative terminal from the battery prior to beginning the
installation.
3. For easier assembly: If additional wiring is required, we recommend running all wires prior to mounting your speaker in place.
4. Use the highest quality connectors for a reliable installation and to minimize signal or power loss.
5. Use caution before you drill or cut! Be careful not to cut or drill into gas tanks, fuel lines, brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle.
6. Never run speaker wires underneath your vehicle. Running speaker wires inside the vehicle provides the best protection from exhaust heat and environmental elements.
7. Avoid running wires over, near, or through sharp edged surfaces. We suggest you also use rubber grommets to protect any wires routed through metal.
8. When running the speaker cable from the amplifier, avoid running it near sources of high current (i.e. wiring harnesses, battery cables).
