Page 2
3
User Guide (English)
Introduction
Box Contents
Support
DN-500BD
Power Cable
Remote Control Rack Ears & Screws
User Guide
Safety & Warranty Manual For the latest information about this product (system
requirements, compatibility information, etc.) and
product registration, visit denonpro.com.
Safety Instructions
Please also see the included Safety & Warranty Manual for more information.
Before turning the
power on: Make sure all connections are secure and correct and that there are no
problems with the connection cables.
Power is supplied to some of the circuitry even when the unit is powered off.
When the unit will not be used for long periods of time, disconnect the power
cable from the power outlet.
Proper ventilation: If the unit is left in a room which is not properly ventilated or is full of smoke
from cigarettes, dust, etc. for long periods of time, the surface of the optical
pickup may get dirty, causing incorrect operation.
About condensation: If there is a major difference in temperature between the inside of the unit and the
surroundings, condensation may form inside the unit, causing the unit not to
operate properly. If this happens, let the unit sit for an hour or two while powered
off, and wait until there is little difference in temperature before using the unit.
Cautions on using
mobile phones: Using a mobile phone near this unit may cause noise. If this occurs, move the
mobile phone away from this unit when it is in use.
Moving the unit: Before moving the unit, turn off its power and disconnect the power cable from
the power outlet. Next, disconnect its connection cables from other devices
before moving it.
About care: Wipe the cabinet and control panel clean with a soft cloth.
Follow the instructions when using a chemical cleaner.
Do not use benzene, paint thinner, insecticide, or other organic solvents to
clean the unit. These materials can cause material changes and discoloration.
Rackmount warnings:
(required rack specifications
for mounting the unit in a
rack)
EIA standard 19-inch (483 mm) rack
1U-size installation compatible rack
Rack that has a guide rail or shelf board that can
support this device
Rack installation: This product will work normally when the player unit is
mounted within 10° off the vertical plane at the front
panel. If the unit is tilted excessively, the disc may not
load or unload properly. (See image.)
Unit Maximum 10°
Page 17
18
To play a playlist:
1. Go to the highest folder in the Media Center.
2. Select the Playlist folder and then press OK.
3. Select the folder for the desired file type: Photo, Music, or Video.
4. Select the file from which you want to start playback, and then press Play (
) on DN-500BD or the
remote control, or press OK on the remote control. The playlist will start playing.
To remove files from a playlist:
1. Go to the highest folder in the Media Center.
2. Select the Playlist folder and then press OK.
3. Select the folder for the desired file type: Photo, Music, or Video.
4. Select the file you want to remove from the playlist, and then press the right cursor button (). A
checkmark will appear next to the file. Repeat this for other files you want to remove from the playlist
that are in the same folder. (If you exit a folder, all checkmarks will be erased.)
To select all files in the current folder, press Title Popup, select Select All, and then press OK.
Checkmarks will appear next to all files.
To deselect all files in the current folder, press Title Popup, select Clear All, and then press OK. All
checkmarks next to the files will be erased. Alternatively, exit the folder.
5. When at least one file is selected (has a checkmark), press Title Popup, and then press OK to select
Remove from Playlist. The selected files in that folder will be removed from the playlist. (This does not
erase those files from the USB drive. The files will still be in their original folders.)
A bookmark is a specific location in a video that is stored in DN-500BDs memory. You can set up to 12
bookmarks and then jump to those locations directly, saving you the time of scanning through the video
later.
To create a bookmark, press Mark on the remote control at the desired location during video playback.
The screen will show the number of the bookmark, current title, current chapter, and current time.
To jump to a bookmark:
1. Press and hold Mark on the remote control for 6 seconds. Playback will pause and the available
bookmarks will appear on the screen.
2. Use the left/right cursor buttons () to move through the bookmarks. When you select a
bookmark, you will see the current title, current chapter, and current time above it. The available
bookmarks are white, and unused bookmarks are gray.
3. Press OK to jump to the desired bookmark. Playback will resume from t
hat bookmarks location.
To can
cel the operation and return to normal playback, press Mark.
To erase a bookmark:
1. Press and hold Mark on the remote control for 6 seconds. Playback will pause and the available
bookmarks will appear on the screen.
2. Press Clear to erase the last-created bookmark.
3. Press Mark to close the bookmarks and return to normal playback.
