Speci cations subject to change without prior notice. Latest
information available at www.crownaudio.com.
Crown and Crown Audio
are registered trademarks of Crown
International. Other trademarks are the property of their
respective owners. Printed in U.S.A.
© 2008 Crown Audio
®, Inc.
VOX Threshold: Trim pot controls how loud the
voice on CH1 must be before muting other chan-
nels. Can be set for no muting.
CoolingConvection cooled.
ProtectionIncluded protection mechanisms are current limit-
ing, over-temperature thermal cutout, and DC-fault
load protection. The unit is protected against
turn-on/turn-off thumps.
Included Accessories Power cord
Non-touch cover for output connectors
Phoenix-type connectors
Optional AccessoriesPart no. IST 600-ohm Isolation Transformer for
Telephone Output or Input 1.
Part no. RM1 single rack mount kit for mounting a 160MA back panel
Crowns Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for every new Crown mixer-ampli-
er-an unsurpassed industry standard. With this unprecedented No-Fault protection, your new Crown \
mixer-ampli er is warranted to meet or exceed original speci cations for the rst three years of owner-
ship. During this time, if your mixer-ampli er fails, or does not perform to original speci cations, it will
be repaired or replaced at our expense. About the only things not covere\
d by this warranty are those
losses normally covered by insurance and those caused by intentional abu\
se. And the coverage is
transferable, should you sell your mixer-ampli er.
See your authorized Crown dealer for full warranty disclosure and detail\
s. For customers outside of the
USA, please contact your authorized Crown distributor for warranty infor\
mation or call 574-294-8200.
135MA
single MA unit in a rack.
Part no. RM2 double rack mount kit for mounting
two MA units side-by-side in a rack.
Part no. S-Cover 10-pack of security knobs.
DimensionsWidth: Half rack width (9.5 in. or 24.1 cm).
Height (front panel): 3.5 in. (8.9 cm).
Height (including feet): 4.1 in. (10.5 cm).
Depth (front panel to back panel): 12.2 in. (31.0
cm).
Depth (front of knobs to back panel): 13.9 in. (35.2
cm).
Weight
Net Weight:
135MA: 8 lb 2 oz (3.7 kg).
160MA: 9 lb 7 oz (4.3 kg).
Shipping Weight:
135MA: 10 lb 16 oz (4.9 kg).
160MA: 12 lb 4 oz (5.6 kg).
160MA
