Line Out Connector: One 3-pin balanced Phoenix-
type connector per output channel. Post master,
pre-VCA. Level controlled by master volume
control.
Amp Input Connector:
3-pin Phoenix-type, high-impedance balanced,
one per amplifer channel.
CoolingConvection cooled.
ProtectionCurrent Limit Protection: Included.
Thermal Limit Protection: Over-temperature
thermal cutout.
DC-Fault Load Protection: Included.
Included Accessories Power cord
Detachable rack ears
Screws for rack ears
Non-touch cover for output connectors
Phoenix-type connectors
Spade lugs
Optional Accessories
1-VCAP remote volume control for one channel.
4-VCAP remote volume control for four channels.
DimensionsEIA Standard 19-inch (48.3-cm) rack mount width
(EIA RS-310-B) with rack ears, 3.5-inch (8.9-cm)
height and 12.2-inch (31.0-cm) depth behind the
mounting surface (not including non-touch cover).
4.1 inches (10.5 cm) high including feet. 13.9
inches (35.2 cm) deep from front of knobs to back
of non-touch cover.
Weight
Net Weight:
180A: 21.0 lb (9.5 kg)
280A: 25.3 lb (11.5 kg)
1160A: 25.3 lb (11.5 kg)
Shipping Weight:
180A: 26.0 lb (11.8 kg)
280A: 30.3 lb (13.7 kg)
1160A: 30.3 lb (13.7 kg)
280A back panel. 180A and 1160A are similar except for the number of ch\
annels.
Crowns Three-Year, No-Fault, Fully Transferable Warranty
Crown offers a Three-Year, No-Fault, Fully Transferable Warranty for every new Crown ampli er--an
unsurpassed industry standard. With this unprecedented No-Fault protection, your new Crown \
ampli er
is warranted to meet or exceed original speci cations for the rst three years of ownership. During this
time, if your ampli er fails, or does not perform to original speci cations, it will be repaired or replaced
at our expense. About the only things not covered by this warranty are t\
hose losses normally covered by
insurance and those caused by intentional abuse. And the coverage is tra\
nsferable, should you sell your
ampli er.
See your authorized Crown dealer for full warranty disclosure and detail\
s. For customers outside of the
USA, please contact your authorized Crown distributor for warranty infor\
mation or call 574-294-8200.
