The lightning flash with arrow-
head symbol, within an equilat-
eral triangle, is intended to alert
the user to the presence of
uninsulated "dangerous volt-
age" within the product's enclo-
sure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICE-
ABLE PARTS INSIDE, REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.The exclamation point within an
equilateral triangle is intended to
alert the user to presence of im-
portant operating and mainte-
nance (servicing) instructions in
the literature accompanying the
appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
IMPORTANT
Since the CD circuity may cause interference to other radio tuners nearby, switch
this unit off when not in use or move it away from the affected radio tuner.
DANGER
LASER SAFETY
This unit employs an optical laser beam system in the CD mechanism, de-
signed with built -in safeguards. Do not attempt to disassemble, refer to
qualified service personnel.
Exposure to this invisible laser light beam may be harmful to the human eye.
THIS IS A CLASS-1 LASER PRODUCT. USE OF CONTROLS, OR ADJUST-
MENTS OR PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN, MAY
RESULT IN HAZARDOUS LASER LIGHT BEAM EXPOSURE.
INVISIBLE LASER
RADIATION WHEN
OPEN AND INTER-
LOCK FAILED OR
DEFEATED. AVOID
DIRECT EXPOSURE
TO LASER BEAM.
Page 2
3
LOCATION OF CONTROLS
23. Fast Rewind
24. Fast Forward
25. Stop/Eject
26. Pause
27. Tape B
28. Function Indicator (AUX)
29. Function Indicator (Tuner/Band)
30. Surround On/Off Knob
31. Memory/C-Adj. Knob
32. Bass Boost On/Off Knob
33. Volume Knob
34. Preset Repeat/Random
35. Tuning Knob
36. CD Play/Pause Knob
37. CD Stop Knob
38. Disc Tray Open/Close Knob
39. Disc Selector
40. Indicator BBS (Bass Boost System)
41. Indicator Surround Sound
42. Disc Tray
43. Preset Equalizer Knob
44. FM Mode Stereo/Mono Knob 1. LCD Display
2. Selector Disc (Disc 3) Button
3. Selector Disc (Disc 2) Button
4. Selector Disc (Disc 1) Button
5. Power ON/OFF Button
6. Stand By Indicator
7. Remote Sensor
8. Timer Knob
9. Mute Knob
10. Mode/Remain Knob
11.Hi-Speed Dubbing On/Off
12. Phone Jack
13. Function Indicator (Tape)
14. Function Indicator (CD)
15. Tape A
16. Record
17. Play
18. Fast Rewind
19. Fast Forward
20. Stop/Eject
21. Pause
22. Play
16
18 19 20 21 22 23 24 25 26 1739
12
14
15 13
6
8
9
107
11
2
3
4
5
31
29
28
27 30
35
32 3334
37
36 38
1
42 4344
41
40
