Page 1
Safety Precautions * This product is designed for use in moderate dimares. Do not use or installPositioning the unit this unit where it would be exposed to direct sunlight or in extremely hot * A minimum distance of 6 INCHES must be maintained to provide sufficient
temperatures, or near a radiator, stove or appliance that produces heat. ventilation.
* Do not take this unit into the bathroom, or near a swimming pool. Do not use * Allow adequate ventilation for the unit ventilation should not be impeded by
it where it would be exposed to water, moisture, dripping or splashing. covering the ventilation openings with items such as newspapers, table cloths,
* No objects filled with liquids, such as vases, shall be placed on the product. curtains etc. Donot stand it on a thick pile carpet, or install it in a place with
* No naked flame sources, such as lighted candies, should be placed on the product. poor air flow.
* If water gets inside the unit. Unplug the power cord from the supply socket * Place the unit on a flat even surface.
and consult your dealer. * Do not use the unit in excessively hot, cold, dusty, damp or humid place.
* Do not handle the power cord with wet hands. To avoid electric shock, * Condensation may form inside the CD player if the unit is left anywhere warm
NEVER touch any internal parts. Repairs/Servicing should be left to qualified and damp, or if you move the unit from somewhere cold (e.g. Your car boot)
service personnel. to a warm room. In this case, let the unit stand for 1-2 hours, or gradually increase
* When connecting or disconnecting from the mains supply, hold the plug, not the room temperature so the unit is dry before you use it.
the cord. Pulling the cord may damage it and could be dangerous. * Do not place it where it could be subject to vibration.
* Do not drop the unit, spill liquid into it or allow objects to fall in it. * Do not place it where it could be magnetised by a magnet or speaker since there
* If the unit fails to operate, disconnect from the mains and consult qualified are magnets in the speakers, do not place tapes or magnetic cards on them as
service personnel. recorded data could be erased.
* When plugged in, a very small current will flow. To save electricity and for * When this unit is used near a TV, the TV picture could be distorted. If this
safety when not using the unit for an extended period of time, it is recommended happens, move the unit away from the TV. If this does not correct the situation,
that the product is completely disconnected at the AC mains socket. avoid using the unit when the TV is turned on.
* Consult your nearest dealer when damage, disconnection or contact failure is * Keep the CD door closed so the lens is not contaminated by dust. Do not touch
found with the cord. the lens.
* Do not bend the cord sharply, pull or twist it.
* Do not modify the power cord in any manner.
* Do not insert any metallic object into the unit.Safety Mechanism: * Unplug the power cord when there is the possibility of lighting. This unit incorporates a safety interlock mechanism which switches the laser beam
on and off, so that when the disc holder is open, the laser beam stops automatically.
2
Page 2
Technical specifications Care & Maintenance General
Cleaning CDs
Power Supply AC 230V ~ 50 Hz
AC 110V/220V ~ 60/50 Hz (option) Use a soft cloth to wipe off any fingerprints and dust from the disc surface.
Wipe in a straight line from the centre to the outside of the disc. Small dust
Output Power 2.5 Watt RMS per channel particles and light stains will not affect reproduction quality.
5.0 Watt RMS per channel (option)
* Never use chemicals such as record sprays, anti-static sprays, benzine or
Main Unit Dimension 220 (L) X 160 (W) X 250 (H) mm thinners to clean your CDs.
Speaker Box Dimension 197 (L) X 160 (W) X 246 (H) mm
* To reduce the risk of scratches, always put CDs back in their cases after use.
Net Weight 4 Kgs with Plastic Speaker Boxes
6 Kgs with Wooden Speaker Boxes (option) * Do not expose CDs to direct sunlight, high humidity or high temperatures
for long periods. Radio frequency coverage FM 88 - 108 MHz * Do not stick paper or write anything on either side of the CD.
AM/MW 540 - 1600 KHz
530 - 1710 KHz (option) * Only discs displaying this symbol can be played on this unit. CD Player Optical Pick Up 3 beams, Semi-conductor Laser
Cleaning the Lens
Frequency Response 100Hz - 16 KHz
A dirty lens will cause sound skipping and, if the lens is very dirty, the CD may Cassette Player
not work. Open the CD door an dclean the lens as follows:
Tape Speed 4.75 CM/Sec.
Frequency Response 125 Hz - 8 KHz * Unplug the power supply.
Bias System DC Bias * Dust or Dry Particles:
Using a camera lens brush/blower, blow on the lens a couple of times, then
Speaker Section
wipe it lightly with the brush to remove dust. Then blow on the lens once more.
Speakers : 3.5" Full Range Speaker X 2 * Finger Prints:
2" Tweeter Speaker X 2 (option) If the lens cannot be cleaned by using a brush/blower, use a dry cotton swab
Impedance : 4 Ohms. and starting in the middle work to the outside edge.
Headphones : 3.5mm stereo jack plug, 8-32 Ohms
3
