Page 1
Front of Crossover BRX10.2
BRX10.2
Under Jack Plate
Back Under
Connect to HF Driver
Blue (+)
White ( -)
HFD10
Connect the Blue and White wir es to the HF driver. I am holding the wires in my
hand to make it easier for you to see which wire to connect to the speaker .
Connect to Woofer s
White ( -)
Red (+)
White ( -)
Red (+)
NE10 -8
Com ments or questions email us at carvinservice@carvin.com
