2 Contents Introduction ......................................................................................................................3 Important safety instructions ..........................................................................................4 Limited warranty ..............................................................................................................7 Rear panel connections...................................................................................................8 Front panel controls .......................................................................................................10 Remote control...............................................................................................................12 iPod compatibility ..........................................................................................................13 Connections ...................................................................................................................14 Aerials .............................................................................................................................15 Operating instructions ...................................................................................................16 Setting the source.................................................................................................16 Adjusting the volume ............................................................................................16 Adjusting the audio settings .................................................................................17 Tuning and listening ..............................................................................................17 Setting presets ......................................................................................................18 Setting the clock ...................................................................................................19 Setting the time zone (US version only) ..............................................................19 Setting the alarm ..................................................................................................20 Setting the sleep time ..........................................................................................20 Advanced settings.................................................................................................21 To re-name the Aux input .....................................................................................21 Using the supplied DD30 docking station for iPod ............................................22 iPod compatibility .................................................................................................22 Connecting and using a SIRIUS Connect Home Tuner (US version only) ..........23 Factory reset ..................................................................................................................24 Troubleshooting..............................................................................................................24 Technical specifications ................................................................................................25 Make sure you register your purchase. Visit: www.cambridge-audio.com/sts By registering, youll be the first to know about:
Future product releases
Software upgrades
News, events and exclusive offers plus competitions! This guide is designed to make installing and using this product as easy as possible. Information in this document has been carefully checked for accuracy at the time of printing; however, Cambridge Audio's policy is one of continuous improvement, therefore design and specifications are subject to change without prior notice. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer. All trademarks and registered trademarks are the property of their respective owners. © Copyright Cambridge Audio Ltd 2009 iPod is a trademark of Apple Inc., registered in the U.S. and other countries. "SIRIUS" and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.

Page 2

3 AR30 DR30 ENGLISH Thank you for purchasing your Sonata AR30/DR30. We are confident that you will enjoy many years of listening pleasure from it. Like all Cambridge Audio products, the Sonata AR30/DR30 adheres to three core principles -“ stunning performance, ease of use and incredible value. The Sonata AR30 and DR30 were jointly developed to offer truly uncompromised audiophile quality audio in a small convenient and stylish package. The Sonata AR30 is a stereo receiver featuring high quality amplification with an in-built FM/AM tuner and supplied DD30 docking station for iPod. The US version of the AR30 additionally features a SIRIUS-Ready socket to allow satellite radio to be added in that country (requires a SIRIUS subscription). The Sonata DR30 is an alternative stereo receiver featuring the same amplification and DD30 iPod dock but with a DAB/FM tuner for countries which broadcast DAB digital radio. The supplied remote can control all of the Sonata AR30/DR30s functions and those of an iPod when docked in the matching DD30 dock (supplied). The audio circuitry draws on all our previous experience and features a true discrete high power amplifier, linear power supply and low flux toroidal transformer. Alarm and Sleep timer functions are available and you may choose to wake to the Tuner or attached iPod. A temporary aerial is supplied to get you going, however the use of appropriate external AM/FM/DAB aerials is strongly recommended to really get the best from your Sonata AR30/DR30. Ultimate sound quality depends on the whole of your system, naturally we particularly recommend speakers from the Cambridge Audio Sirocco range as these have been designed for a perfect acoustic and aesthetic match. Your dealer can also supply excellent quality Cambridge Audio interconnects to ensure your system realises its full potential. Thanks for taking the time to read this manual; we do recommend you keep it for future reference. Matthew Bramble Cambridge Audio Technical Director and the Sonata range development team Introduction
