Cambridgeaudio incognito lm 10 owners manual

This is the 20 pages manual for cambridgeaudio incognito lm 10 owners manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 20
left right
cambridgeaudio incognito lm 10 owners manual

Extracted text from cambridgeaudio incognito lm 10 owners manual (Ocr-read)


Page 1

2Incognito LM10 CONTENTS Introduction......................................................3 Specifications...................................................3 System Set-up ..................................................4 Mounting the LM10..........................................6 Fitting the LM10...............................................6 Safety precautions...........................................7 Faceplates........................................................7 Wiring guide......................................................7 Cat-5 connections............................................8 Single local audio source set-up............................9 Dual LM10s fitted in a single zone.......................11 Single LM10 with main and sub-zone fitted..12-13 Dual LM10s with main and sub-zones fitted.......14 Source rotate for local 1 & 2............................... on the keypad.................................................15 Audio level adjustment..................................17 Limited warranty.............................................18

Page 2

Incognito LM10 Incognito LM103 Thank you for purchasing this Cambridge Audio Incognito product. The LM10 Local Input Module is an in-wall module that allows the user to add an additional local source to those distributed by the AH10. The local source may only be heard in the room where it is connected and the corresponding sub-zone (if connected) and is not distributed to other rooms. LM10s can be fitted in as many rooms as are desired. The LM10 connects between the audio hub and a KP10 amplified control module using Cat-5/5e wiring. Each main zone can support two LM10s, giving you the option of listening to one or two local sources (eg. Playstation, MP3 player). Each local source can be controlled through the Incognito remote and/or keypad (see instruc- tions on entering local source rotate mode on page 15). The LM10 can also support sub- zones (where fitted) so that the local source is audible in both main and subzone areas. Now we invite you to sit back, relax and enjoy ! Matthew Bramble Technical Director INTRODUCTION SPECIFICATION Max line level inputs 2.2 V rms Cat-5 connection type EU Version - Krone punchdown CU Version - 110 punchdown Dimensions EU Version - 50 x 50 x 48mm CU Version - 44 x 70 x 54mm Weight 100g Maximum cable length 30M/100ft IR (Infra-red output) Modulated 34-“40 kHz and 55-“59 kHz supported Power requirement 24V DC @ 20 mA max (supplied by hub)
