Page 1
SPECIFICATIONS
Voltage AC
As specified on rear panel
Consumption
As specified on rear panel
Dimensions (mm)
80(h) x 430(w) x 300(d)
Frequency
4Hz - 20kHz (-0.5dB)
Signal to Noise Ratio
More than 110dB
Dynamic Range
More than 96dB
Total Harmonic Distortion
0.001% @ 1kHz
Wow and Flutter
Below measurable limits
Audio Output Level
2.4V RMS
Channel Separation
More than 95dB
Jitter
Better than 180pS (weighted)
Cambridge Audios policy is one of
continuous improvement. It is possible
therefore, that specifications and designs
may change without prior notice.
FRONT PANEL CONTROLS
Please refer to page 5 of your owners manual
1 2 7 6 5 4 3
REAR PANEL CONNECTIONS
Please refer to page 4 of your owners manual
1 2 3 4 5
A. Track time indicator
B. Play indicator
C. Track number
D. Random mode indicator
E . Track repeat indicator
E+F.Disc repeat indicator
G. Program mode indicator C A
REPEAT ALL
REPEAT ALL PROGRAM RANDOM
B
D
EF G
