As with previous Cambridge Audio CD players, the CD5 makes use of a
custom Cambridge Audio servo solution and transport, at the heart of
which is a VLSI (Very Large Scale Integration) circuit which dynamically
adjusts in real time the focusing, tracking and output level of the laser
for the maximum retrieval of digital information. To ensure the very best
performance there are also multiple separate power supplies for the
D/A converter circuitry, audio filters, clocks and other stages, as well as
extensive use of low impedance film capacitors.
The CD5 CD player also now features MP3 playback and allows naviga-
tion of MP3 folders on the disc directly from the remote control and front
panel.
Your CD player can only be as good as the system it is connected to.
Please do not compromise on your amplifier, speakers or cabling.
Naturally we particularly recommend amplification from the Cambridge
Audio range, which have been designed to the same exacting standards
as our CD players. Your dealer can also supply excellent quality
Cambridge Audio interconnects to ensure your system realises its full
potential.
Thanks for taking the time to read this manual; we do recommend you
keep it for future reference.
Matthew Bramble
Technical Director
INTRODUCTION
Page 2
The crossed-out wheeled bin is the European Union symbol for indi-
cating separate collection for electrical and electronic equipment.
This product contains electrical and electronic equipment which
should be reused, recycled or recovered and should not be dis-
posed of with unsorted regular waste. Please return the unit or con-
tact the authorised dealer from whom you purchased this product
for more information.
Plug Fitting Instructions (UK Only)
The cord supplied with this appliance is factory fitted with a 13 amp mains plug fit-
ted with a 3 amp fuse inside. If it is necessary to change the fuse, it is important
that a 3 amp one is used. If the plug needs to be changed because it is not suitable
for your socket, or becomes damaged, it should be cut off and an appropriate plug
fitted following the wiring instructions below. The plug must then be disposed of
safely, as insertion into a 13 amp socket is likely to cause an electrical hazard.
Should it be necessary to fit a 3-pin BS mains plug to the power cord the wires
should be fitted as shown in this diagram. The colours of the wires in the mains
lead of this appliance may not correspond with the coloured markings identifying
the terminals in your plug. Connect them as follows:
The wire which is coloured BLUE must be
connected to the terminal which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be
connected to the terminal which is marked
with the letter L or coloured RED.
The wire which is coloured GREEN/YELLOW
must be connected to the terminal which is
marked with the letter E or coloured GREEN.
If your model does not have an earth wire,
then disregard this instruction.
If a 13amp (BS 1363) plug is used, a 3amp fuse must be fitted, or if any other type
of plug is used a 3 amp or 5 amp fuse must be fitted, either in the plug or adaptor,
or on the distribution board.
Checking the Power Supply Rating
For your own safety please read the following instructions carefully before attempting
to connect this unit to the mains.
Check that the rear of your unit indicates the correct supply voltage. If your mains
supply voltage is different, consult your dealer.
This unit is designed to operate only on the supply voltage and type that is indicat-
ed on the rear panel of the unit. Connecting to other power sources may damage
the unit.
This equipment must be switched off when not in use and must not be used unless
correctly earthed. To reduce the risk of electric shock, do not remove the unit's
cover (or back). There are no user serviceable parts inside. Refer servicing to qual-
ified service personnel. If the power cord is fitted with a moulded mains plug the
unit must not be used if the plastic fuse carrier is not in place. Should you lose the
fuse carrier the correct part must be reordered from your Cambridge Audio dealer.
The lightning flash with the arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-insulated dangerous
voltage within the products enclosure that may be of sufficient mag-
nitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and mainte-
nance instructions in the service literature relevant to this appliance.
This product complies with European Low Voltage (73 / 23 / EEC)
and Electromagnetic Compatibility (89 / 336 / EEC) Directives
when used and installed according to this
instruction manual. For continued compliance only Cambridge
Audio accessories should be used with this product and servicing
must be referred to qualified service personnel.
SAFETY PRECAUTIONS
