0 Cambridge Audio

Issue Date: February 20|0

650R

SERVICE MANUAL

SPECIFICATIONS:
Azur 650R 7.1 HDMI 1.3 AVR

HDMI Switching

Analogue Video up-conversion

HDTV capable via component Video or HDMI/ DVI

Decoding formats:

32-bit DSPs, 24/ 192 capable DACS

Post processed Dolby/ DTS modes (convert 5.1
to 7.1)

On-Screen Display (05D)

Separate stereo DAC

Audio Inputs:

Video Inputs:

Audio Outputs:

Video Outputs:

Recording Audio outputs:
Recording Video Outputs:

Other Connections

1.3c, 3 inputs 1 output

transcode any analogue format upwards to the other
analogue formats and to HDMI

LPCM, Dolby Digital/ Dolby Digital EX, DTS/ DTS ES
Matrix/Discrete, PLII/PLIIX, DTS Neo:6, Dolby True HD,
Dolby Digital Plus, DTS-HD Master Audio, DTS-HD High
Resolution Audio, Multi-channel PCM. All in 5.1/6.1 or
7.1 variants

Post process 5.1 or 6.1 formats with PLIIX or Neo:6 to
7.1

Available via composite video, S-video, component
video and HDMI

for left/right from surround channel codec

8 line analogue, tuner (FM/AM), 7.1 analogue input, 5
digital coaxial, 6 digital optical

5 composite, 5 s-Video, 3 component video, 3 HDMI

7 amplified speaker outputs, 7.1 preamp outputs

l composite, l s-Video, 1 component video, 1 HDMI

2 line level analogue, 2 digital coaxial, 2 digital optical
l composite, l s-Video

1 1/4"] 6.35mm headphone output,
Control bus input/output, 1 IR emitter In, 1 RSZ32C, 1
IEC type mains inlet
