GENERAL INSTRUCTIONS

Setup Recommendations:

Congratulations on your purchase of a Bryston
preampliﬁer. We are conﬁdent it will provide you with
many years of mu31cal enjoyment.

You may place your preampliﬁer in any conve»
nient location with two possible exceptions If you own
the Bryston BP<25 remote~control version, position the
preampliﬁer to maintain a direct line-of-sight between the
hand-held remote and the remote sensor eye located on
the left side of the preampliﬁer 5 front panel.

If you purchased the BP-ZSP or BP»25MC,
which includes a Phone section, avoid placing the pream-
pliﬁer directly on top of your power amplifier. Power
ampliﬁers usually employ large power supplies and the
transformed (s) in the power supplies can cause interfer-
ence (hum) with the sensitive phono section inside the
preamp

Next, insert the 5-pin din cable from the out-

board power supply into the input connector located on
the rear of the preampliﬁer. Then plug the power supply
into an appropriate AC power outlet. The preampliﬁer is
powered up by engaging the slide switch located on the
front of the external power supply. The green LED on
the outboard power supply and the preampliﬁer front
panel indicates power-on.
If the preampliﬁer has been placed in the mute
position operating the volume up button on the
remote will automatically inn-mime the BP-ZS pream-
pliﬁer, turning the LED from red to green. On the
BP-ZO you must manually activate the mime toggle
on the front panel. Both the Mute switch and the
Polarity Invert switch are momentary-toggle types, operr
ated by push-and-release.

BP-PS Power Supply:

The BP-PS outboard power supply provides AC
power for the BP-ZO and B1125 preampliﬁers. It has a
slide power switch located on the front and a green LED
to indicate power on.

On the rear of the unit is a three position con-
nector which provides a control voltage for remote tum
on/otf of your Bryston THX ampliﬁer(s) or other ampli~
ﬁers so equipped. This feature can be used in two ways
depending on the wiring arrangement utilized:

Option one provides for the preampliﬁer and
power ampliﬁer to be turned on or off when you
operate the power switch located on the front of the
external power supply. Turning the power off with the
switch on the outboard power supply removes AC power

from both die preampliﬁer and the power ampliﬁer(s) for
complete system shut-down.

Option two allows the power ampliﬁer(s) to
be turned on or off with the mute button on the
hand-held remote control unit or the mute togle on
the front panel of the preampliﬁer. This will shut down
your system for the night, completely removing power
from the ampliﬁers, but leaving the preamp in the Mute /
standby mode, indicated by the red LED on the preamplie
ﬁers front panel

Please refer to the diagram on the included
separate instruction sheet for further clarity and optional
wiring arrangements.

Connections:

Connect the preampliﬁeis left and right outputs
from either the RCA or Balanced XLR connectors to the
appropriate left and right input jacks on your power
ampliﬁer. Balanced cables are an advantage if you are
using long runs of cable, (greater than 20 feet), between
your preampliﬁer and power ampliﬁer,

Connect your CD player, tuner, tape deck, video
recorder, or laser disc, etc. to the speciﬁc left/ right pream-
pliﬁer inputs.With phonoeequipped models, (BF-25? or
BPeZSMC), connect your phono cables to the phono
input jacks. If your turntable leads have a separate ground
wire, it may be connected to the ground lug adiacent to
the phono inputs on the rear panel.

The Bryston B13420 and BP-ZS preamps also
feature two pairs of balanced XLR input jacks. Many
signal sources, including CD~players and separate D/A
converters are now available with Balanced outputs for
minimum noise pickup on the cables.

The tape loop may be used to insert a surround
sound processor, cassette tape deck or video tape recorder
into your system. Plug your tape deck or external proces-
sors input cables into the To Tape jacks, and the proces-
sot or decks output cables into the From Tape jacks at
the rear of the preamp. The tape or processor loop may
be operated via the toggle switch located on the front
panel of the preampliﬁer.
