BowersWilkins DM 601 S3 Owners Manual
This is the 31 pages manual for BowersWilkins DM 601 S3 Owners Manual. Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com .
Download PDF
Extracted text from BowersWilkins DM 601 S3 Owners Manual (Ocr-read)
Page 1
Figure 1
Figure 2a
Figure 3
Figure 2b
Figure 4
>0.5m
>0.5m
>1.5m
---
Page 2
Contents
English
Limited Warranty...........1
Owners Manual ............1
Français
Garantie limitée.............2
Manuel dutilisation .......2
Deutsch
Beschränkte Garantie ...4
Bedienungsanleitung.....4
Español
Garantía limitada...........5
Manual de
instrucciones ................6
Português
Garantia limitada...........7
Manual do utilizador .....7
Italiano
Garanzia limitata ...........8
Manuale di istruzioni .....9
Nederlands
Beperkte garantie .......10
Handleiding ................10
Ελληνικά
Περιρισμένη
εγγύηση....................11
δηγίες ρήσεως....12
"esky
Záruka .......................13
Návod k pouãití..........13Polski
Gwarancja .................14
Instrukcja
uÃytkownika ...............15
Русский
Ог-аниченная
га-антия....................16
Руководство по
эксплуатации............16
Slovenska navodila
Omejena garancija ....17
Navodila za
uporabo .....................18
Dansk
Begrænset garanti ......19
Brugervejledning .........19
Suomi
Takuuehdot.................20
Omistajan kasikirja ......20
Svenska
Begränsad garanti ......21
Bruksanvisning ...........22
Magyar
Korlátozott garancia ..23
Használati útmutató ...23
.......................24
.....................24
.......................25
....................26
Page 29
DM601 S3 DM602 S3
Technical Features
Description
Drive Units
Frequency Range
Frequency Response
Dispersion
Sensitivity
Harmonic Distortion
Nominal Impedance
Crossover Frequency
Recommended Amplifier
Power
Max. Recommended Cable
Impedance
Dimensions
Net Weight Nautilus- tweeter
Kevlar® brand fibre cone bass/midrange
Flowport
2-way vented-box system
1x ø25mm (1 in) alloy dome high-frequency
1x ø165mm (6.5 in) woven Kevlar®
cone bass/midrange
-6dB at 48Hz and 42kHz
60Hz - 22kHz ±3dB on reference axis
Within 2dB of reference response
Horizontal: over 40˚ arc
Vertical: over 10˚ arc
88dB spl (2.83V, 1m)
2nd and 3rd harmonics (90dB, 1m)
<1% 88Hz - 20kHz
8Ω(minimum 3.0Ω)
4kHz
25W - 100W into 8Ωon
unclipped programme
0.1Ω
Height: 365mm (14.4in)
Width: 204mm (8in)
Depth: 228mm (9in)
6.1 kg (13.4 lb) Nautilus- tweeter
Kevlar® brand fibre cone bass/midrange
Flowport
2-way vented-box system
1x ø25mm (1 in) alloy dome high-frequency
1x ø180mm (7in) woven Kevlar®
cone bass/midrange
-6dB at 40Hz and 42kHz
49Hz - 22kHz ±3dB on reference axis
Within 2dB of reference response
Horizontal: over 40˚ arc
Vertical: over 10˚ arc
90dB spl (2.83V, 1m)
2nd and 3rd harmonics (90dB, 1m)
<1% 60Hz - 20kHz
8Ω(minimum 3.0Ω)
4kHz
25W - 120W into 8Ωon
unclipped programme
0.1Ω
Height: 490mm (19.3in)
Width: 236mm (9.3in)
Depth: 293mm (11.5in)
10.5 kg (23.1 lb)
