Boston acoustics gta 1005 owners manual

This is the 12 pages manual for boston acoustics gta 1005 owners manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 12
left right
boston acoustics gta 1005 owners manual

Extracted text from boston acoustics gta 1005 owners manual (Ocr-read)


Page 1

Specifications 2 Introduction Thank you for choosing Boston Acoustics and congratulations, youve made the right choice. Youre now equipped for the open road. Your high performance GTA amplifiers are engineered to perform and built to last. These products represent the pinnacle of performance and innovation that Boston Acoustics is famous for. We hope you enjoy your amplifier and the road ahead. Technical Specifications: Front & Rear Channels Subwoofer Channel Rated Power (CEA2006A): @4Ohm (Stereo): 50 Watts x 4 N/A @2Ohm (Stereo): 80 Watts x 4 N/A @4Ohm (Mono): 160 Watts x 2 250 Watts x 1 @2Ohm (Mono): N/A 400 Watts x 1 Impedance Stability: 2 ΩSt /4Ω Mono 2 Ω Frequency Response (3dB): 10Hz-50kHz 10Hz-150Hz SignaltoNoise Ratio: >90dB >90dB (A Weighted) THD+N:0.050.05 Highpass Crossover: Frequency Range:50Hz 200Hz10Hz 50Hz Slope (dB Per Octave): 12dB 12dB Lowpass Crossover: Frequency Range:50Hz 200Hz50Hz 150Hz Slope (dB Per Octave): 12dB 12dB Signal Voltage Input Range: Low Level (RCA) Input: 200mv 5v Speaker Level Input: 400mv 10v Fuse Amp Rating (ATC):3x25 Amp Dimensions: Width: 21 1-4(538mm) Height:23-8(60mm) Depth: 8 3-8 (211mm) Parts List: Owners Manual: x 1 2mm Hex Wrench: x 1 3mm Hex Wrench: x 1 4mm Hex Wrench:x1 Speaker Level Input Cable:x1 Mounting Screws: x 4 Replacement Fuses (ATC):x 3(25 amp)

Page 2

Connections/Controls 3 Status LED The Boston Logo will illuminate Blue under normal operating conditio\ ns. The LED will illuminate Red during startup and under fault conditio\ ns. If the LED is still red after startup, please refer to troubleshooting on page\ 10. RCA Input (Left and Right)Speaker Level Input Speaker Level Input Crosssover Filter Switch (HP / Off / LP) Gain (250mv to 5.0v continuously variable) Crossover Frequency Adjustment (50Hz to 200Hz continuously variable)\ QTune -Q Adjustment (0.707 to 1.6 cont. variable) Lowpass Crossover Adjustment (50Hz to 150Hz cont. variable)) QTune -Highpass (Subsonic) Adjustment (10Hz to 50Hz cont. variable) GTARSL Port (Remote Gain) Speaker Output Block (Front and Rear Speakers) Speaker Output Block (Subwoofer) Status LED (Blue = Normal / Red = Fault Mode) Fuses (Replace with same value only ,refer to specifications on page 2) Power Block (12v / Remote / Ground) Connections and Controls Speaker Level Input Cable GT Aamplifiers offer a dedicated speaker level input for ease installation i\ nto factory systems when an RCA (low level) signal is not available. Wirin\ g code for the cable is industry standard; White Solid = Left Positive White w/ Black Stripe = Left Negative\ Gray Solid = Right Positive Gray w/ Black Stripe = Right Negative W arning: Do not connect both Speaker Level and RCAs into the amplifier at\ the same time as damage to the amplifier may occur . 15 11 5 447126121011131492135412358
