Declaration
of Conformity
We, the offerer:
Bose
® Corporation, The Mountain
Framingham, MA 01701-9168 USA
acknowledge our sole responsibility, that the product:
Kind of equipment:Loudspeakers
Type designation:Acoustimass
® -6
Home Theater Speakers
in accordance with EMC Directive 89/336/EEC and Article 10(1) of the Directive,
is in compliance with the following norm(s) or document(s):
Technical regulations:EN50081-1, EN50082-1
Accredited by Bose Corporation
21 February 1997
Bose B.V., Nijverheidstraat 8 Anton Schalkamp
1135 GE Edam, General Manager, Bose Europe
The Netherlands Manufacturers authorized EU representative
Introduction
Thank you
We appreciate your choice of the Bose ® Acoustimass ®-6 home theater speaker system. With
these Virtually Invisible ® speakers you will surround yourself with realistic sound, without a
lot of equipment.
For your records
The serial number is located near the connection panel on the Acoustimass module.
Serial number: _________________________________________________________________
Dealer name: __________________________________________________________________
Dealer phone: _______________________ Purchase date: ___________________________
We suggest you keep your sales slip and warranty card together with this owners guide.
Page 2
AM189815_04_V.pdf December 20, 2001 3
Contents
Where to find...
Setting Up
Before you begin ........................................................................................................ 4
Unpack the carton ...................................................................................................... 5
Placing your Acoustimass
®-6 speakers to achieve realistic home theater sound ...... 6
Select the locations for your speakers ....................................................................... 7
Left and right front cube speakers ...................................................................... 7
Center cube speaker ........................................................................................... 8
Surround cube speakers ..................................................................................... 8
Acoustimass module ........................................................................................... 9
Connect the speakers .............................................................................................. 10
Connect the Acoustimass module to the center and front cube speakers ...... 10
Connect the module to the surround cube speakers ....................................... 11
Connect the module to the receiver .................................................................. 11
Check the connections ..................................................................................... 12
Attach the module end cover, if needed ........................................................... 13
Using Your Acoustimass-6 Speakers
For realistic home theater sound .............................................................................. 14
How to set your Pro-Logic receiver .................................................................. 14
How to set your Dolby Digital (AC-3) receiver ................................................... 14
Maintaining Your Acoustimass-6 Speakers
Troubleshooting ........................................................................................................ 15
Cleaning the speakers .............................................................................................. 15
Product Information
Warranty period ........................................................................................................ 16
Technical information ............................................................................................... 16
Accessories .............................................................................................................. 17
Bose
® Corporation ................................................................................. inside back cover
