Page 1
Settin g Up YourLifes tyle ®Stereo Am pli er
English
M odelAV-18/ 38/48 m ediacen tersetup
CAUTION: Beforemakingconnections,turntheLifestyle® system o and disco nnectthe med ia
centerfrom theAC(mains)poweroutlet.DONOTplugtheamplierintoanoutletuntilyouhave
completedallotherconnections.
1. InsertoneendoftheBose ®linkAcableintotheBose ®linkoutputconnectorontherear
panelofthemediacenter(Figure5).
2. InserttheotherendoftheBose ®linkAcable,intotheBose ®linkinputconnectoronthe
rearpaneloftheLifestyle ®stereoamplier.
Figure5
Lifest yle®stereoamplierto AV-18/38/48mediacenter connections
BoseLinkOUTPUT
BoseLinkINPUT
Lifestyle®stereoamplierrearpanel AV-18/38/48mediacenterrearpanel
20-ftBose®linkAcable
2
Page 2
Setting Up YourLif estyle ®Stereo Am pli er
English
Setting up RC-18 Sand RC -38S rem otes
Youradditionalremoteisshippedfrom thefactoryalreadysetupforasecondroom (room B).
Tomakesurethatthisremotewillworkwithyourhomeentertainmentsystem,dothefollow-
ingtocheckthehousecodesetting.
1. Removetheremotecontrolbatterycoverandlocatethemicroswitches(Figure6).
2. Makesurethatthehousecodesettings(switches1,2,3,and4)matchthehousecode
settingsinyourmainroom remote.
Note:Ifthisremoteistobeusedbeyondasecondroom, otherswitchsettings willneedtobe
change d.See SettingUpAdditionalRoo msForSoundonpage22.
Figure6
Remotemic roswitches
Chec kthe expansion protoco lsett ing inyou rsystem
FortheLifestyle ®stereoampliertoworkproperlywith yourhomeentertainmentsystem,the
expansionprotocolmenuitem mustbesetto Bose ®link.Toverifythis:
1. TurnonyourLifestyle ®DVDhomeentertainmentsystem andyourTV.
2. Pressthe System buttononyourmainroom remote.
3. Selectthe Audio tabandnavigatedownto ExpansionProtocol.
4. Verifythatthesetting Bose ®link isselected.Ifnot,select Bose ®link now.
5. Pressthe Exitbuttonontheremote.
ON
Housecodeswitches
mustmatchmainroom remo te
3
