Bose esp 88c and esp 00 engineered sound processors sm rev01

Page 1

JEEP

Better sound through research®

ControlSpace® ESP-88C and ESP-00
Engineered Sound Processors,
CC-16 and CC-64 Controllers
(US and non-US units)

- o x
-
C C; 0 0 - 7. f": .
CC-64 Control Center 0016 Zone Controller
©2009 Bose Corporation Service Manual

Reference Number 313419-SM Rev. 01
Electronic Copy Only

Page 2

CONTENTS

Safety Information ..................................................................................................................................... 3
Warranty ......................
Product Description
Specifications .............
Electrostatic Discharge Sensitive (ESDS) Device Handling
Part List Notes ............................................................................
Packaging Part List, ControlSpace® ESP-88C and ESP-00 Chassis
Figure 1. ESP-BBC/ESP-OO Chassis Packing View ......
Packaging Part List, ControlSpace CC-16 Controller
Figure 2. 00-16 Controller Packing View .....................
Packaging Part List, ControlSpace CC-64 Controller
Figure 3. 00-64 Controller Packing View ......................................................
Main Part List, ControlSpace ESP-880/ESP-00 Chassis (see Figure 4) .
Figure 4. ControlSpace ESP-8SC/ESP-00 Chassis Exploded View
Main Part List, ControlSpace CC-16 Controller
Figure 5. ControISpace CC-16 Controller Exploded View
Main Part List, ControlSpace CC-64 Controller .............
Figure 6. ControISpace CC-64 Controller Exploded View
Electrical Part List .........................................................................
ESP-88C and ESP-00 Chassis Motherboard PCB Assembly..
ESP-88C Chassis 4x4 Series II PCB Assembly ...........................
ESP-88 Digital Signal Processor (DSP) PCB Assembly
ESP-88 Output PCB Assembly
ESP-88 LED PCB Assembly
CC-64 Control Center .....
CC-16 Zone Controller
Disassembly Procedures ...............
ESPBBC and ESP-00 Front Panel Indicators and Features
ESP880 and ESP-00 Rear Panel Controls and Connections
Test Procedures ............................................................................
Figure 7. ATS-2, ESP-88C/ESP-OO and AuBit Switchbox Test Setup Diagram .....................
Figure 8. Astec LPT83 Switch Mode Power Supply ......
DC Power Supply +5V Adjustment Procedures . 102-103
Troubleshooting .................................................................. 104
Service Manual Revision History ................................................................................................. 105
