Page 1
2 -“ English
NoticeThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that in terference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, you are encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a different circuit than the one to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Bose Corporation could void the users authority to operate
this equipment.
These devices comply with FCC and In dustry Canada RF radiation exposure limits set forth for the general
population. They must not be co-located or be operating in conjunction with any other antennas or transmitters.
These devices comply with Industry Canada license-e xempt RSS standard(s). Operation is subject to the
following two conditions: (1) This device may not cause interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation of the device.
CAUTION: Refer to the CineMate ® 1 SR setup guide for sa fety-related information.
Please complete and retain for your records:
Speaker array serial number (on bottom panel): __________________________________
Acoustimass module serial nu mber (on back panel): ______________________________
Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent #s: 5,956,674; 5,974,380 and
6,487,535 & other worldwide patents issued & pending. DTS, the DTS Symbol
and DTS + the DTS Symbol are registered trademarks & the DTS logos are
trademarks of DTS, Inc. Produc t includes software. ©2010 DTS, Inc. All Rights Reserved.
©2011 Bose Corporation. No part of this work may be reproduced, modified, distributed, or
otherwise used without pr ior written permission.
Page 2
English -“ 3
CONTENTS
CONTROLS AND INDICATORS 4
Universal remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4Turning the system on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controlling the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Programming the universal remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Reading the system indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting the bass level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CONTROLLING S OURCES 7
Changing the source control mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Watching TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Watching a DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Navigating on-screen menus and guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using playback controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CARE AND M AINTENANCE 12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Replacing the remote batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning your speaker system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
